TP-Link Archer VR300 User Manual

15
Chapter 4
Set Up Internet Connections
5. Scroll down the page, enable IPv6, and configure the IPv6 parameters.
• Addressing Type: Consult your ISP for the addressing type (DHCPv6 or SLAAC).
SLAAC is the most commonly used addressing type.
• IPv6 Gateway: Keep the default setting as Current Connection.
Note: If your ISP has provided the IPv6 address, click Advanced to reveal more settings. Check to use IPv6
specified by ISP and enter the parameters provided by your ISP.
6. Click OK to make the settings effective. Now IPv6 service is available for your
network.
4. 5. Wireless Router Mode
If you already have a modem or your internet comes via an Ethernet jack on the wall, you
can set up the modem router as a regular wireless router to share the internet.
1. Find the WAN port (labeled as LAN4/WAN) on the modem router, and connect it
to your existing modem or the Ethernet jack on the wall. Then connect the power
adapter and turn on the modem router. If you connect an existing modem, reboot it
to get the modem router connected to the internet.
2. Connect your computer to the modem router. For details, refer to Connect Your
Modem Router.
3. Visit http://tplinkmodem.net, and log in with your TP-Link ID or the password you
set for the router.
4. Go to Advanced > Operation Mode, select the Wireless Router Mode, and click
Save. The modem router will reboot.
5. Go to Basic > Internet, select the Connection Type, and enter the information
provided by your ISP.

TP-Link Archer VR300 Specifications

General

Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11h
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11b)	20 dBmW
Security algorithms	IPSec, WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Output current	1 A
Output voltage	12 V
Product type	Tabletop router
Product color	Black
RJ-11 ports quantity	1
Ethernet LAN (RJ-45) ports	4
Certification	CE, RoHS, RCM
Cables included	LAN (RJ-45), Phone (RJ-11)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990
Package depth	240 mm
Package width	330 mm
Package weight	840 g

Weight and Dimensions

Depth	76 mm
Width	385 mm
Height	290 mm
