Chapter 12
VPN Server
12. 1. Use IPSec VPN to Access Your Home Network
IPSec VPN is used to create a VPN connection between local and remote networks.
To use IPSec VPN, you should check that both local and remote routers support IPSec
VPN feature. Then, follow the steps below to set up an IPSec VPN connection.
1. The typical VPN topology is here. Site A refers to local network, and Site B refers to
the remote network that is to be connected. Record Site A and Site B’s LAN and WAN
IP addresses before you start configuration.
Modem router 1
LAN: 192.168.1.1
WAN: 219.134.112.246
PC 1
Subnetmask: 255.255.255.0
WAN: 219.134.112.247
Modem Router 2
PC 2
LAN: 192.168.2.1
Subnetmask: 255.255.255.0
Site A
Site B
2. Configuration on Site A (local network).
1 ) Visit http://tplinkmodem.net, and log in with your TP-Link ID or the password
you set for the router.
2 ) Go to Advanced > VPN > IPSec VPN, and click Add.
