TP-Link Archer VR300 User Manual

Chapter 6
IPTV
IPTV is the abbreviation of Internet Protocol Television. The service can only be delivered
through the Internet, and our modem router provides a specific LAN port for IPTV.
By automatically separating IPTV from Internet surfing, you can enjoy a high quality of
video streaming and fast browsing speeds at the same time.

TP-Link Archer VR300 Specifications

General

Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11h
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11b)	20 dBmW
Security algorithms	IPSec, WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Output current	1 A
Output voltage	12 V
Product type	Tabletop router
Product color	Black
RJ-11 ports quantity	1
Ethernet LAN (RJ-45) ports	4
Certification	CE, RoHS, RCM
Cables included	LAN (RJ-45), Phone (RJ-11)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990
Package depth	240 mm
Package width	330 mm
Package weight	840 g

Weight and Dimensions

Depth	76 mm
Width	385 mm
Height	290 mm
