TP-Link Archer VR300 User Manual

40
Chapter 10
Network Security
2 ) Click Bind to add to the Binding List.
To bind the unconnected device
1 ) Click Add.
2 ) Enter the MAC address and IP address that you want to
bind.
3 ) Select the check box to enable the entry and click OK.
Enjoy the internet without worrying about ARP spoofing and
ARP attacks.
10. 5. IPv6 Firewall
IPv6 Firewall protects your IPv6 network by preventing access from the internet.
However, when you are hosting a service, such as a file sharing server in your local
network, you can choose to allow access to the server from the internet by adding
entries on this page. This feature is available only when you’ve set up an IPv6 connection.
1. Visit http://tplinkmodem.net, and log in with your TP-Link ID or the password you
set for the router.
2. Go to Advanced > Security > IPv6 Firewall.
3. Click Add.
Done!

TP-Link Archer VR300 Specifications

General

Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11h
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11b)	20 dBmW
Security algorithms	IPSec, WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Output current	1 A
Output voltage	12 V
Product type	Tabletop router
Product color	Black
RJ-11 ports quantity	1
Ethernet LAN (RJ-45) ports	4
Certification	CE, RoHS, RCM
Cables included	LAN (RJ-45), Phone (RJ-11)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990
Package depth	240 mm
Package width	330 mm
Package weight	840 g

Weight and Dimensions

Depth	76 mm
Width	385 mm
Height	290 mm
