TP-Link Archer VR300 User Manual

58
Chapter 13
Specify Your Network Settings
13. 2. 1. Configure the RADVD Address Type
1. Visit http://tplinkmodem.net, and log in with your TP-Link ID or the password you
set for the router.
2. Go to Advanced > Network > LAN Settings.
3. Select IPv6 to configure IPv6 LAN parameters.
Note:
If you have created an interface group, you can configure IPv6 LAN settings for the default interface group only.
1 ) Select the RADVD address type to make the modem router assign IPv6 address
prefixes to hosts.
Note:
Do not select the Enable RDNSS and Enable ULA Prefix check boxes unless required by your ISP. Otherwise
you may not be able to access the IPv6 network. For more information about RDNSS and ULA Prefix, contact
our technical support.
2 ) Keep Site Prefix Type as the default value Delegated. If your ISP has provided a
specific IPv6 site prefix, select Static and enter the prefix.
3 ) Keep Prefix Delegated WAN Connection as the default value.
4. Click Save to make the settings effective.
13. 2. 2. Configure the DHCPv6 Server Address Type
1. Visit http://tplinkmodem.net, and log in with your TP-Link ID or the password you
set for the router.
2. Go to Advanced > Network > LAN Settings.
3. Select IPv6 to configure IPv6 LAN parameters.
Note:
If you have created an interface group, you can configure IPv6 LAN settings for the default interface group only.

TP-Link Archer VR300 Specifications

General

Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11h
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11b)	20 dBmW
Security algorithms	IPSec, WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Output current	1 A
Output voltage	12 V
Product type	Tabletop router
Product color	Black
RJ-11 ports quantity	1
Ethernet LAN (RJ-45) ports	4
Certification	CE, RoHS, RCM
Cables included	LAN (RJ-45), Phone (RJ-11)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990
Package depth	240 mm
Package width	330 mm
Package weight	840 g

Weight and Dimensions

Depth	76 mm
Width	385 mm
Height	290 mm
