Chapter 1
Get to Know Your Modem Router
Item
Description
POWER Port
For connecting the modem router to a power socket via the provided
power adapter.
ON/OFF Button The switch for the power. Press it to power on or off the modem router.
RESET Button
Press and hold down for about 2 seconds to reset the modem router
into factory default settings.
WPS Button Press to start a WPS synchronization.
LAN1, LAN2, LAN3,
LAN4/WAN Port
For connecting the modem router to your PC or other Ethernet network
devices. In wireless router mode, the LAN4/WAN port is used for
connecting to a Cable/FTTH/VDSL/ADSL device.
DSL Port
For connecting the modem router to the internet. Connect the port to
the splitter or directly connect the port to the phone jack via a phone
cable. For details, please refer to Connect Your Modem Router.
Antennas
Used for wireless data transmission. Position them upright for the best
performance.
