9
Chapter 2
Connect the Hardware
DSLPhone2Phone1
Phone 2Phone 1
Modem Router
TAE Socket
Power Adapter
Power Socket
Turn on the modem router.
Install the antennas.
N F N
Connect the TAE-RJ45 adapter to the modem router
using an RJ11-to-RJ45 cable, then connect the
TAE-RJ45 adapter to the TAE socket.
1
2
3
Wait for about 1 minute until the DSL LED is solid on.
4
2. Connect your computer to the modem router.
Method 1: Wired
Connect your computer’s Ethernet port to the LAN port on the modem router via the
Ethernet cable.
LAN
Method 2: Wirelessly
Use the default SSID (Wireless Network Name) and Wireless Password printed on
the included Wi-Fi Info Card or on the product label of the modem router to connect
wirelessly.
To Next Page
