Figure 6-3 AP List
Device Name:
Displays the name of the device. The default format of device name is “model-
MAC address” (such as EAP115-00-0a-eb-9a-2a-ac).
Model:
Displays the model of the device.
MAC:
Displays the MAC address of the device.
IP:
Displays the IP address of the EAP. By default, it is obtained from a DHCP server
(typically a router).
Role:
Displays the role of the EAP in a cluster, including Master and Member.
Status:
Displays the status of an EAP in a cluster, including connected and joining.
Connected: The EAP has joined a cluster.
Joining: The EAP is trying to join a cluster.
Clients:
Displays the number of wireless devices connected to the EAP.
Settings:
Operations here are only valid for a specific EAP.
: Click to configure the parameters of the EAP.
: Click to remove the EAP from the cluster, thus the management mode of
the removed EAP will switch to Standalone.
: Click to reboot the EAP.
Click to configure the wireless parameters of a specific EAP. The following content will be
shown.
Figure 6-4 Configure the Wireless Parameters
