Configuration Procedure:
Step Operation Description
1 Bind the IP address, MAC
address, VLAN ID and the
connected Port number of
the Host together.
Required. On the IP-MAC Binding page, bind the IP
address, MAC address, VLAN ID and the connected Port
number of the Host together via Manual Binding, ARP
Scanning or DHCP Snooping.
2 Enable the protection for the
bound entry.
Required. On the Network Security→IP-MAC
Binding→Binding Table page, specify a protect type for
the corresponding bound entry.
3 Specify the trusted port. Required. On the Network Security→ARP
Inspection→ARP Detect page, specify the trusted port.
The specific ports, such as up-linked port, routing port
and LAG port, should be set as Trusted Port.
4 Enable ARP Detect feature. Required. On the Network Security→ARP
Inspection→ARP Detect page, enable the ARP Detect
feature.
11.2.2 ARP Defend
With the ARP Defend enabled, the switch can terminate receiving the ARP packets for 300
seconds when the transmission speed of the legal ARP packet on the port exceeds the defined
value so as to avoid ARP Attack flood.
Choose the menu Network Security→ARP Inspection→ARP Defend to load the following page.
Figure 11-14 ARP Defend
The following entries are displayed on this screen:
¾ ARP Defend
Port Select: Click the Select button to quick-select the corresponding port
152

TP-Link JetStream L2 Lite TL-SG3210 Specifications

General

Model	TL-SG3210
Category	Switch
Type	Managed
Switching Capacity	20Gbps
Forwarding Rate	14.88 Mpps
MAC Address Table	8K
Jumbo Frame	9KB
Certifications	CE, FCC, RoHS
Ports	8 x 10/100/1000Mbps RJ45 ports, 2 x 1G SFP slots
Standards and Protocols	IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s
VLAN	4K VLAN IDs
Operating Temperature	0°C~40°C (32°F~104°F)
Storage Temperature	-40°C~70°C (-40°F~158°F)
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 90% non-condensing
