Monitoring Traffic Traffic Monitor
Configuration Guide
127
Refresh Rate: Specify the refresh interval in seconds.
2) In Port Select, select a port or LAG, and click Select.
3) In the Statistics section, view the detailed information of the selected port or LAG.
Received: Displays the detailed information of received packets.
Broadcast: Displays the number of valid broadcast packets received on the port.
Error frames are not counted in.
Multicast: Displays the number of valid multicast packets received on the port.
Error frames are not counted in.
Unicast: Displays the number of valid unicast packets received on the port. Error
frames are not counted in.
Jumbo: Displays the number of valid jumbo packets received on the port. Error
frames are not counted in.
Alignment Errors: Displays the number of the received packets that have a Frame
Check Sequence (FCS) with a non-integral octet (Alignment Error). The size of the
packet is between 64 bytes and 1518 bytes.
UndersizePkts: Displays the number of the received packets (excluding error
packets) that are less than 64 bytes long.
Pkts64Octets: Displays the number of the received packets (including error
packets) that are 64 bytes long.
Pkts65to127Octets: Displays the number of the received packets (including error
packets) that are between 65 and 127 bytes long.
Pkts128to255Octets: Displays the number of the received packets (including
error packets) that are between 128 and 255 bytes long.
Pkts256to511Octets: Displays the number of the received packets (including
error packets) that are between 256 and 511 bytes long.
Pkts512to1023Octets: Displays the number of the received packets (including
error packets) that are between 512 and 1023 bytes long.
PktsOver1023Octets: Displays the number of the received packets (including
error packets) that are over 1023 bytes.
Sent: Displays the detailed information of sent packets.
Broadcast: Displays the number of valid broadcast packets transmitted on the
port. Error frames are not counted in.
Multicast: Displays the number of valid multicast packets transmitted on the port.
Error frames are not counted in.
Unicast: Displays the number of valid unicast packets transmitted on the port.
Error frames are not counted in.
Jumbo: Displays the number of valid jumbo packets transmitted on the port.
Error frames are not counted in.
Collisions: Displays the number of collisions experienced by a half-duplex port
during packet transmissions.
