TP-Link T1600G Series - 802.1 X Configuration; Using the GUI; Configuring the RADIUS Server

Configuration Guide 571
Configuring Network Security 802.1X Configuration
6
802.1X Configuration
To complete the 802.1X configuration, follow these steps:
1) Configure the RADIUS server.
2) Configure 802.1X globally.
3) Configure 802.1X on ports.
Configuration Guidelines
802.1X authentication and Port Security cannot be enabled at the same time. Before
enabling 802.1X authentication, make sure that Port Security is disabled.
6.1 Using the GUI
6.1.1 Configuring the RADIUS Server
Enable AAA function on the switch, configure the parameters of RADIUS sever and
configure the RADIUS server group.

Enabling AAA function
Choose the menu Network Security > AAA > Global Config to load the following page.
Figure 6-1 Enable AAA Function
In the Global Config section, enable AAA function on the switch and click Apply.
