TD-W8901G 54M Wireless ADSL2+ Router User Guide
29
Figure 4-21
¾ Virtual Circuit: Enter Virtual Circuit Index that you plan to setup for the NAT function.
¾ NAT Status: This field shows the current status of the NAT function for the current VC. You
can go to the previous screen (shown in Figure 4-4) to activate the function.
¾ Number of IPs; This field is to specify
how many IPs are pr
ovided by your ISP for current VC.
It can be single IP or multiple IPs. We select Multiple to explain.
)
Note:
For VCs with single IP, they share the same DMZ and Virtual servers; for VCs with multiple IPs,
each VC can set DMZ and Virtual servers. Furthermore, for VCs with multiple IPs, they can define
the Address Mapping rules; for VCs with single IP, since they have only one IP, there is no need
to individually define the Address Mapping rule.
4.4.3.1 DMZ
Choose “Ad
vanced Setup→NAT→DMZ” in Figure 4-21, you can configure the DMZ host in the
next screen. A DMZ (demilitarized zone) is a host be
tween a private local network and the outside
public network. It prevents outside users from getting direct access to a server that has company
data. Users of the public network outside the company can access to the DMZ host.
Figure 4-22
¾ DMZ Host IP Address: Enter the specified IP Address for DMZ host on the LAN side.
4.4.3.2 Virtual Server
Choose “Ad
vanced Setu
p→NAT→Virtual Server” in Figure 4-21, you can configure the Virtual
Server in the
next screen.
