TP-Link TL-SG1016DE User Manual

2.3 Switch Discovery
When the utility is launched, it immediately searches the network for TP-Link Easy Smart
Switches.
The discovered switches are listed as below.
Figure 2-7 Main Page
Click Help in the left bottom to access the TP-Link support website for more help.
Note:
The maximum number of the discovered switches is 30.
2.4 Switch Setting
You can select a switch and click to configure or display its status.
Figure 2-8 Discovered Switch
9

TP-Link TL-SG1016DE Specifications

General

Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
Power connector	AC-in jack
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
10G support	No
Number of VLANs	32
Networking standards	IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Virtual LAN features	Port-based VLAN, Tagged VLAN
Cable types supported	Cat3, Cat5, Cat6
Copper ethernet cabling technology	100BASE-TX, 100BASE-T, 1000BASE-T
Jumbo frames	9000
Forwarding rate	23.8 Mpps
Number of queues	4
MAC address table	8000 entries
Packet buffer memory	0.512 MB
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (max)	19.15 W
Stackable	-
Form factor	1U
Product color	Black
Housing material	Metal
Heat dissipation	34.52 BTU/h
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Maximum cable length	100 m
Compatible operating systems	Windows
Package type	Box
Package depth	400 mm
Package width	250 mm
Package height	80 mm
Package weight	1910 g
Sustainability certificates	CE, Federal Communications Commission (FCC), RoHS

Weight and Dimensions

Depth	180 mm
Width	284 mm
Height	44 mm
