System Routing Table”, and you can views all of the
valid route entries in use. The Destination IP address, Subnet Mask, Gateway, and Interface will
be displayed for each entry.
Figure 4-74 Routing Table
Destination Network - The Destination IP Address is the address of the network or host to
which the static route is assigned.
Subnet Mask - The Subnet Mask determines which portion of an IP address is the network
portion, and which portion is the host portion.
Gateway - This is the IP address of the gateway device that allows for contact between the
Router and the network or host.
Interface - This interface tells you whether the Destination IP Address is on the LAN &
WLAN (internal wired and wireless networks), the WAN (Internet).
Click the Refresh button to refresh the data displayed.
4.15 Bandwidth Control
Figure 4-75 The Bandwidth Control menu
There are two submenus under the Bandwidth Control menu as shown in Figure 4-75. Click any
of them, and you will be able to configure the corresponding function. The detailed explanations
for each submenu are provided below.
4.15.1 Control Settings
Choose menu “Bandwidth Control
