Chapter 6 Events and Alerts
6. 7 Disk Exception
Alarm actions will be triggered when the NVR detects disk problems. You can select triggered actions
for three exception types. Follow the steps below to finish the configuration.
1. Right click on the Live View screen and click Settings in the pop-up main menu, then go to Event >
Exception Detection > Disk Exception.
2. Select the alarm actions according to your needs:
Screen Prompt
A warning sign
in the lower right corner of the monitor screen. Enable
it to check the event type and time.
Buzzer The buzzer on the NVR will beep when disk problems are detected.
3. Click Save to save the settings.

TP-Link VIGI NVR1008H Specifications

General

Input bandwidth	80 Mbit/s
Output bandwidth	60 Mbit/s
Maximum resolution	1920 x 1080 pixels
Video input channels	8 channels
Supported resolutions	1920 x 1080, 1280 x 720, 1440 x 900, 1280 x 1024
Video recording modes	1080p
Number of simultaneously playbacked channels	4 channels
Product color	Black
Rack capacity	1U
Rack mounting	Yes
Wi-Fi	No
HDD capacity	0 GB
HDD interface	Serial ATA
Maximum storage capacity	0 TB
Number of HDDs installed	0
Number of HDDs supported	1
USB 2.0 ports quantity	2
Power supply	18 W
Output voltage	12 V
Operating temperature (T-T)	-10 - 55 °C
Harmonized System (HS) code	85219000

Weight and Dimensions

Depth	148.2 mm
Width	246.2 mm
Height	42.6 mm
Weight	578.5 g
Package depth	296.5 mm
Package width	277.5 mm
Package height	64.5 mm
Package weight	1070 g
