PAGE 13
9070 Vibration Analysis Copyright © 2012 Test Products International, Inc.
2.3.3.2 Units
Selecting Units from the Advanced
Settings menu allows the velocity
readings to be displayed in either
mm/s or in/s (inch/second).
Run Speed units can be displayed in
units of Hertz3 (Hz), RPM or CPM.
2.3.3.3 Device Settings
There are two pages of Device
Settings menus. To advance to the
second page the right arrow button
should be used. Selecting a menu
option is again achieved by pressing
the square button.
The Auto Off Time can be set from 1
minute up to a maximum value of 60
minutes, in increments of 1 minute.
The Brightness level can be set
anywhere between 1 (least brightness)
up to 100 (full brightness).
----------------------------------------------------------------------------------------------
3
Hertz are equivalent to, and also sometimes referred to as, cycles per second (CPS).
4
Revolutions per minute (RPM) are sometimes also referred to as cycles per minute (CPM)
