9070 Vibration Analysis Copyright © 2012 Test Products International, Inc.
4 Specifications
5 Revision History
Size
7.9” x 2.4” x 1” (200 mm x 60mm x 26mm)
Weight
9.9oz. (280g) (not including magnet)
Environmental
Water, Sand & Dust:
IP67 Waterproof (Depth of 3.28’ (1m) up to 30 minutes)
Care must be taken when batteries are changed. Make sure gasket
is properly seated otherwise IP67 rating will be compromised.
Never open the meter housing. There are no user serviceable parts
inside. Opening the housing will compromise the IP67 rating.
Operating:
32°F to 122°F (0°C to 50°C)
Storage:
-4°F to 158°F (-20°C to 70°C)
Power supply
2 x AA batteries
Battery life
Auto power OFF - typically 50 hours operating time
depending on brightness setting.
Frequency range
2 Hz to 1 kHz (ISO)
1 kHz to 15 kHz (BDU)
Max frequency resolution
1.25 Hz @ 800 lines FFT setting
Displayed Vibration
Amplitude Units
Acceleration in g
Velocity in mm/s (or inch/s)
Bearing noise in BDU (bearing damage units)
Displayed Frequency Units
Hertz (Hz), RPM or CPM
Input range
+/- 50g
Dynamic range
72 dB (0.05g resolution)
VA diagnostic bands
(RPM = run speed)
Unbalance 1x RPM
Alignment 2x RPM
Looseness 3x RPM
Accessories
• Screw in probe tip (1/4" UNF 28) part number A9071
• Nylon carrying case part number A9070
Options
• Accelerometer mounting magnet part number A9073
• Extended probe tip (stinger) part number A9072
ISSUE PAGES DATE NOTES
1.0 16 March 2012 First Issue - JKA
