Connector pin assignment for SCART sockets
View from outside
VCR DVD and SET-TOP BOX TV
Pin RGB / Video S-Video RGB / Video S-Video RGB / Video S-Video
1
Audio Out (R) Audio Out (R) --- --- Audio Out (R) Audio Out (R)
2
Audio In (R) Audio In (R) Audio In (R) Audio In (R) Audio In (R) Audio In (R)
3
Audio Out (L) Audio Out (L) --- --- Audio Out (L) Audio Out (L)
4
Audio earth Audio earth Audio earth Audio earth Audio earth Audio earth
5
Earth
Chroma Out
earth
Blue In earth Earth Blue Out earth Chroma In earth
6
Audio In (L) Audio In (L) Audio In (L) Audio In (L) Audio In (L) Audio In (L)
7
--- Chroma Out Blue In --- Blue Out Chroma In
8
Switch voltage Switch voltage Switch voltage Switch voltage Switch voltage Switch voltage
9
Earth Earth Green In earth Earth Green Out earth Earth
10
Control signal Control signal Control signal Control signal Control signal Control signal
11
--- --- Green In --- Green Out ---
12
--- --- --- --- --- ---
13
Earth Chroma In earth Red In earth Earth Red Out earth
Chroma Out
earth
14
Earth Earth Blanking earth Earth Blanking earth Earth
15
--- Chroma In Red In Chroma In Red Out Chroma Out
16
--- --- Blanking --- Blanking ---
17
Video Out earth Lumin. Out earth Earth Earth Video Out earth Lumin. Out earth
18
Video In earth Lumin. In earth Video In earth Lumin. In earth Video In earth Lumin. In earth
19
Video Out Lumin. Out --- --- Video Out Lumin. Out
20
Video In Lumin. In Video In Lumin. In Video In Lumin. In
21
Earth Earth Earth Earth Earth Earth
