DHCP on
If your network includes a DHCP server, please select the ON setting at this
point. In this mode an IP address is automatically assigned to the MP 200 by
the router. The screen shows only the MAC address and the message DHCP
state ON. In this case the address input elds shown in the illustration do not
appear in the menu.
off
If your network does not include a DHCP server, please select the OFF set-
ting. In this mode you must congure the following network settings manually.
Please ask your network administrator for the addresses to be entered for your
network.
IP IP Adress of the MP 200
Subnet mask Network mask
Gateway IP Adress for the router
DNS Name / IP of the name server (optional)
Store and exit? Stores the network parameters, and restarts the MP 200 with the new settings
Discard and exit? Closes the menu: data already entered is discarded
Connecting to WLAN (radio connection)
• Connect the supplied WLAN antenna to the WLAN
socket on the back of the MP 200. Depending on your
reception and set-up situation, the antenna can be
mounted directly on the socket on the back or toge-
ther with the magnetic base supplied (see g.).
• Switch on the MP 200.
• Open the menu for system settings and then the
menu item Network.
Menu item Setting / Explanation
MAC The MAC address is a hardware address which uniquely identies your machi-
ne. The address displayed is determined by the manufacturer, and cannot be
altered.
Conncetion state Shows the connection state: WLAN, LAN or not connected.
WPS autoconnect Activates the WPS function to connect the MP 200 to the WLAN via WPS. See
chapter Setup via the WPS function.
Scan for WLAN Starts the scan for WLAN networks that are within reception range.
WLAN access point Starts the access point mode to set up the WLAN connection via the T+A App TA
Music Navigator. See chapter Conguration via Access Point.
j
All other menu items are the same as for the connection via LAN. See above for more information.
32
