Parts & Features
7
Vapor is equipped with a backlight for easy viewing during night-time
operation.
Using External 12V Power:
• Vapor will light up with all five LED’s.
• Vapor will remain lit as long as it senses wheel movement. After
20 minutes of inactivity Vapor shuts off the backlight. Press any
button, roll the wheels, or start the motor power and Vapor will light
up again.
• Shift and Temperature LED’s will be enabled.
Using Internal Battery Only:
• Vapor will only stay lit for 3 seconds.
• Vapor’s backlight will light up with 10% power to conserve battery
power.
• If the LO symbol is present, the backlight will not turn on. The LO
symbol appears when battery voltage drops below 2.45V.
• If ambient temperature is cold (below -5°C) the backlight will not
TO ACTIVATE BACKLIGHT MANUALLY, PRESS
Backlight:
If connected to 12V power, press any key to activate the backlight.
