RT-SVX34V-EN
21
Table 5. Approximate unit operating weight
Approximate Unit Operating Weight (lb)
Unit (60Hz)
TC TE YC Low
YC High
27.5 Tons 4183 4303 4468 4651
30 Tons 4195 4315 4480 4663
35 Tons 4226 4346 4511 4694
40 Tons 4821 5044 5130 5409
50 Tons 4878 5101 5187 5466
Notes:
1. Weights shown are for standard efficiency units and include the following features: 10HP supply fan motor, supply fan VFD, 100% economizer, 2" MERV 8 filters,
SZVAV system control, GFCI, no exhaust, and hail guards.
2. Weights shown are subject to change based on the specific unit configuration.
3. Weights shown represent approximate operating weights and have a ±10% accuracy. To calculate weight for a specific unit configuration, utilize Trane Select
Assist™ or contact your local Trane® sales representative.
4. As-configured weights are stamped on unit nameplate.
Table 6. Approximate operating weights— optional components — lbs./kg
Unit Model
(60Hz/50Hz)
Baro.
Relief
Power
Exhaust
0-25%
Man
Damper
Econ.
Var. Freq. Drives
(VFD’s)
Serv.
Valves
Thru-the
base
Elec.
Non-
Fused
Discon.
Switch
Factory
GFI with
Discon.
Switch
Roof Curb
HGRH
Coil
W/O With
Bypass
Lo Hi
**(D,F)330/275
110/50 167/76 50/23 260/117 108/49 114/52 18/8 6/3 30/14 85/38 310/141 330/150 107/49
**(H,R)330/275
145/65 191/87 50/23 285/128 108/49 114/52 18/8 6/3 30/14 85/38 310/141 330/150 107/49
**(D,F)360/305
110/50 167/76 50/23 260/117 108/49 114/52 18/8 6/3 30/14 85/38 310/141 330/150 107/49
**(H,R)360/305
145/65 191/87 50/23 285/128 108/49 114/52 18/8 6/3 30/14 85/38 310/141 330/150 107/49
**(D,F)420/350
110/50 167/76 50/23 260/117 108/49 114/52 18/8 6/3 30/14 85/38 310/141 330/150 107/49
**(H,R)420/350
145/65 191/87 50/23 285/128 108/49 114/52 18/8 6/3 30/14 85/38 310/141 330/150 107/49
**(D,F)480/400
110/50 167/76 50/23 290/131 150/68 158/72 18/8 6/3 30/14 85/38 365/169 365/169 112/51
**(H,R)480/400
145/65 191/87 50/23 300/135 150/68 158/72 18/8 6/3 30/14 85/38 365/169 365/169 112/51
**(D,F)600/500
110/50 167/76 50/23 290/131 150/68 158/72 18/8 6/3 30/14 85/38 365/169 365/169 112/51
**(H,R)600/500
145/65 191/87 50/23 300/135 150/68 158/72 18/8 6/3 30/14 85/38 365/169 365/169 112/51
Unit Model
(60Hz/50Hz)
Con-
denser
Hail
Guards
Ultra
Low
Leak
Econ
Ultra
Low
Leak
50%
Exhaust
Ultra
Low
Leak
100%
Exhaust
eStage,
High
Efficien-
cy
**(D,F)330/275
105/48 112/51 34 / 15 74 / 34 251/114
**(H,R)330/275
105/48 78/35 34 / 15 77 / 35 251/114
**(D,F)360/305
105/48 112/51 34 / 15 74 / 34 251/114
**(H,R)360/305
105/48 78 /35 34 / 15 77 / 35 251/114
**(D,F)420/350
105/48 112/51 34 / 15 74 / 34 175/79
**(H,R)420/350
105/48 78/35 34 / 15 77 / 35 175/79
**(D,F)480/400
130/59 114/52 34 / 15 74 / 34 196/89
**(H,R)480/400
130/59 100/45 34 / 15 84 / 38 196/89
**(D,F)600/500
130/59 114/52 34 / 15 74 / 34 70/32
**(H,R)600/500
130/59 100/45 34 / 15 84 / 38 70/32
Unit Dimensions and Weights
