AC-SVX001A-EN
17
Dimensions and Weights
Weights
Table 3. Unit weights
Standard Length Extended Length
Shipping Operating Shipping Operating
Unit Size
(tons)
lb
kg
lb
kg
lb
kg
lb
kg
InvisiSound™ Standard or Superior
150 11333 5141 11479 5207 13492 6120 13638 6186
165 12377 5614 12533 5685 14532 6592 14688 6662
180 12698 5760 12881 5843 14853 6737 15036 6820
200 13808 6263 14008 6354 15991 7254 16191 7344
225 15244 6915 15466 7015 17427 7905 17649 8006
250 15622 7086 15862 7195 17805 8076 18045 8185
275 16820 7630 17095 7754 18975 8607 19250 8732
300 17965 8149 18265 8285 20121 9127 20421 9263
InvisiSound™ Ultimate
150 12133 5504 12279 5570 14292 6483 14438 6549
165 13177 5977 13333 6048 15332 6955 15488 7025
180 13498 6123 13681 6206 15653 7100 15836 7183
200 14608 6626 14808 6717 16791 7616 16991 7707
225 16044 7278 16266 7378 18227 8268 18449 8368
250 16422 7449 16662 7558 18605 8439 18845 8548
275 17620 7992 17895 8117 19775 8970 20050 9095
300 18765 8512 19040 8636 20921 9490 21196 9614
Notes:
1. Weights include factory charge of refrigerant and oil, as well as architectural louvered panels. See Unit Length section of General Data chapter
to determine unit length.
2. Model number digit 12 = 1 or 2
3. Model number digit 12 = 3
