Table 4. Unit dimensions, standard length
Unit Size
150 165 180 200
225, 250
275 300
Dim in
mm
in
mm
in
mm
in
mm
in
mm
in
mm
in
mm
A 158.6 4027.0 211.4 5368.8 212.5 5397.4 265.3 6739.5 265.3 6739.5 318.1 8080.5 370.9 9422.5
B 52.4 1330.0 105.2 2671.9 103.5 2629.4 156.4 3971.5 156.4 3971.5 209.0 5308.5 261.8 6650.5
C 11.8 300.0 11.8 300.0 11.8 300.0 11.8 300.0 11.8 300.0 11.8 300.0 11.8 300.0
D 51.2 1300.0 51.2 1300.0 51.2 1300.0 51.2 1300.0 51.2 1300.0 51.2 1300.0 51.2 1300.0
E 78.8 2000.0 74.8 1900.0 74.8 1900.0 74.8 1900.0 74.8 1900.0 61.4 1560.0 74.8 1900.0
F 63.0 1600.0 118.1 3000.0 118.1 3000.0 100.8 2560.0 100.8 2560.0 72.4 1840.0 100.8 2560.0
G 76.4 1940.0 76.4 1940.0 137.8 3500.0 174.8 4440.0
H 25.0 635.0 25.0 635.0 25.0 635.0 25.0 635.0 25.0 635.0 25.0 635.0 25.0 635.0
I 128.1 3255.0 145.6 3699.0 145.6 3699.0 65.9 1674.0 65.9 1674.0 65.9 1674.0 65.9 1674.0
J 120.5 3061.0 120.5 3061.0 158.5 4026.0 79.7 2024.0
K 184.5 4686.0
L 223.0 5663.5 275.8 7005.5 275.8 7005.5 328.6 8347.5 328.6 8347.5 381.5 9689.5 434.3 11031.5
M 228.9 5813.0 281.7 7155.0 281.7 7155.0 334.5 8497.0 334.5 8497.0 387.4 9839.0 440.2 11181.0
N 20.4 519.5 20.4 519.5 19.6 497.5 19.6 497.5 21.8 553.6 20.6 522.5 20.6 522.5
O 17.7 449.5 17.7 449.5 15.4 390.5 15.4 390.5 17.6 446.6 16.1 407.7 16.1 407.7
P 49.3 1252.5 49.3 1252.5 49.9 1268.0 49.9 1268.0 49.9 1268.0 51.3 1303.3 51.3 1303.3
Q
38.5 977.5 38.5 977.5 37.9 962.0 37.9 962.0 37.9 962.0 36.5 927.3 36.5 927.3
R 19.3 489.5 19.3 489.5 17.6 447.5 17.6 447.5 19.8 503.6 18.2 462.5 18.2 462.5
S 19.7 499.5 19.7 499.5 18.2 462.5 18.2 462.5 20.4 518.6 18.9 480.5 18.9 480.5
T 15.8 400.0 15.8 400.0 15.8 400.0 15.8 400.0 15.8 400.0 15.8 400.0 15.8 400.0
U 66.9 1700.0 66.9 1700.0 66.9 1700.0 66.9 1700.0 66.9 1700.0 66.9 1700.0 66.9 1700.0
V 59.1 1500.0 55.1 1400.0 55.1 1400.0 55.1 1400.0 55.1 1400.0 41.8 1060.0 55.1 1400.0
W 63.0 1600.0 118.1 3000.0 118.1 3000.0 100.8 2560.0 100.8 2560.0 72.4 1840.0 100.8 2560.0
X 76.4 1940.0 76.4 1940.0 137.8 3500.0 155.1 3940.0
Y 53.6 1362.5 106.5 2704.4 105.5 2679.4 158.3 4021.5 158.3 4021.5 210.3 5340.0 263.1 6682.0
