Getting Started
To properly install an Symbio™ 800 AdaptiView display
upgrade kit, the technician must have good knowledge of the
Symbio 800 control systems. Training in Symbio 800 controls
is highly recommended before beginning this upgrade.
Nameplate
A Symbio™ 800 AdaptiView display upgrade nameplate is
included in the kit to be installed near the original nameplate on
the control panel. Always provide the model number and serial
number information from the nameplate when making
inquiries, ordering parts, or literature for the Symbio 800
AdaptiView display system.
Symbio 800 AdaptiView Display
Upgrade Kit Contents
Figure 1. Symbio™ 800 AdaptiView display upgrade
nameplate example
SYMBIO 800 UPGRADE CONTROL FOR USE ON
LIQUID CHILLERS
MODEL NO: CDUB3A105AA00100000
SERIAL NO: L22C01079
ORDER NO: LARRYSP4
ORIGINAL SERIAL NO: L22A00000
LITERATURE:
SO-SVN037*-EN
CTV-SVU004*-EN
SO-SVP002*-EN
CTV-SVD005*-EN
CVHE-SVX005*-EN
BAS-SVU047*-EN
CTV-SVP004*-EN
www.trane.com/Patent
Table 1. Basic bill of material for Symbio™ 800 control upgrade kit
Description Qty. Part Number
(a)
Mnemonic Part Number
(a)
Display arm 1 X45091462010 ARM00848
Symbio AdaptiView color display 1 X13760359001 MOD03183
Symbio 800 controller 1 X13651678020 MOD02979
Harness; Modbus distribution 1 453730970001 WIR10397
Four plug Phoenix type terminal connector 2 X19220085030 CON00431
DIN Rail end stop 2 X13492732001
Ethernet cable for Symbio 800 to display connection, 3700
mm in length (See, Figure 2, p. 9)
1 X19070632020 CAB01206
Male to Female wire harness extension, 1 meter in length
(See, Figure 3, p. 9)
1 X19051623010 CAB01149
Wire harness extension, Female connector to stripped end, 1
meter in length (Refer to Figure 3, p. 9)
1 X19051625020 CAB01155
2-conductor power supply communication cable, 8 inches in
length (See, Figure 4, p. 9)
1 X19051243010 CAB00974
USB Type B service port cable (See, Figure 5, p. 9) 1 X19140818010 CAB01260
USB Type B service port cap 1 X19201118010 CAP01053
Bushing, 0.88 inch diameter 2 X19100013000 BUS00866
Power supply (for installation as 1A2 power supply) 1 X13650737060 BRD02102
Power supply mounting bracket 1 X19090702010 BRK03306
10-32 x 0.50-inch screw 4 X25330033410 SCR00889
5/16-18 x 1 inch hex head cap screw 4 X25012400000 SCR01839
5/16-inch lockwasher 4 X22020400000
5/16-inch hex nut 4 X28020700000
Serialized nameplate decal 1 X39001817010
Nameplate protector 1 X39001166030
10-32 x 1.00-inch screw 1 X25330033450 SCR01014
Quad relay output 1 X13650806050 BRD04879
Bracket; CH531 sub panel 1 507104470100 BRK05365
Bracket; AdaptiView display Mt. 1 X05010050010 BRK04345
Hex HD screw; 7/16-20*1 3 42250080710
Lockwasher, Helical spring; 7/16 3 X22020026060
Normar size flatwasher; 7/16 3 X22050232150
