Trane CVHF Installation Instructions

AFDH Drive Package Specifications
AFDH-SVN004C-EN 21
Figure 17. Rear view of LF 1/1.5 frame 4 E-Frame AFDH cabinet with dimensions - LiquiFlo drive
58.40
57.62
1
2
1. Tor terminal access cover. Size of cutout is 7.2 in. x 17.6 in.
2. Centerline of Z-bracket mounting studs
