Trane CVHF Installation Instructions

AFDH Drive Package Specifications
22 AFDH-SVN004C-EN
Drive Unit Weights and Heat
Rejection
Table 5. AFDH E-Frame unit weights (380V/480V)
380V/480V
E-Frame AFDH
Maximum amps
658 745 800 880 990
Enclosure Type
Direct
Transiti
on
LF Direct
Transiti
on
LF Direct
Transiti
on
LF Direct
Transiti
on
LF Direct
Transiti
on
LF
Unit Weight (lb)
1402 1437.5 1516.2 1402 1437.5 1516.2 1402 1437.5 1516.2 1452 1487.5 1566.2 1452 1487.5 1566.2
Heat Rejection
(Btu/h)
24306 28084 30632 32984 38539
Table 6. AFDH E-Frame unit weights (460V/480V)
460V/480V
E-Frame AFDH
Maximum amps
590 678 730 780 890
Enclosure Type
Direct
Transiti
on
LF Direct
Transiti
on
LF Direct
Transiti
on
LF Direct
Transiti
on
LF Direct
Transiti
on
LF
Unit Weight (lb)
1402 1437.5 1516.2 1402 1437.5 1516.2 1402 1437.5 1516.2 1452 1487.5 1566.2 1452 1487.5 1566.2
Heat Rejection
(Btu/h)
20835 24323 27856 27310 32176
Table 7. AFDH E-Frame unit weights (575V/600V)
575V/600V E-Frame
AFDH Maximum amps
450 500 570
Enclosure Type
Direct Transition LF Direct Transition LF Direct Transition LF
Unit Weight (lb)
1402 1437.5 1516.2 1402 1437.5 1516.2 1402 1437.5 1516.2
Heat Rejection (Btu/h)
21353 24139 28221
575V/600V E-Frame
AFDH Maximum amps
630 730 850
Enclosure Type
Direct Transition LF Direct Transition LF Direct Transition LF
Unit Weight (lb)
1402 1437.5 1516.2 1452 1487.5 1566.2 1452 1487.5 1566.2
Heat Rejection (Btu/h)
32081 35961 44067
