Trane CVHF Installation Instructions

AFDH Drive Package Specifications
AFDH-SVN004C-EN 25
Table 10. Custom enclosure parts; E-Frame 800 amps model drives (380V/400V)
Trane Assembly Part Numbers for all Optional Model Versions of 380V/400V E-Frame 800 amps AFDH
Figure 18
Callout
Part Description
Trane X-Code Part
Number
Trane Mnemonic
Number
Supplier Part
Number
Quantity
1 4 KVA Transformer X13550916020 1
2 Circuit breaker handle HDL01302 1
3
Circuit breaker handle metal mounting
base
X19091662001 1
4 Circuit breaker
NGH312033E
1
NGC312033E(Opt)
5 Circuit breaker lug
TA1200NB1
3TA1201NB1(Opt)
T1200NB3(Opt)
6 Ground lug X19170060020 2
7 Choke X13640734010 7
8 Choke mounting bracket 506898810100 2
9 Fuse holder; 60A, 600V, 1P X13111194010 1
10 Fuse 40A, 600V X13110755020 1
11 Fuse holder; 30A, 600V, 2P X13111193010 1
12 Fuse 15A, 600V X13110683300 2
13 Arrester; 3-Pole MOV,600V WYE X13641454001 1
Table 11. Custom enclosure parts; E-Frame 880 amps model drives (380V/400V)
Trane Assembly Part Numbers for all Optional Model Versions of 380V/400V E-Frame 880 amps AFDH
Figure 18
Callout
Part Description
Trane X-Code Part
Number
Trane Mnemonic
Number
Supplier Part
Number
Quantity
1 4 KVA Transformer X13580273010 1
2 Circuit breaker handle HDL01302 1
3
Circuit breaker handle metal mounting
base
X19091662001 1
4 Circuit breaker
NGH312033EC
1
NGC312033EC
(Opt)
5 Circuit breaker lug
TA1200NB1
3TA1201NB1(Opt)
T1200NB3(Opt)
6 Ground lug X19170060020 2
7 Choke X13640735010 8
8 Choke mounting bracket 507123430001 2
9 Fuse holder; 60A, 600V, 1P X13111194010 1
10 Fuse 40A, 600V X13110755020 1
11 Fuse holder; 30A, 600V, 2P X13111193010 1
12 Fuse 15A, 600V X13110683300 2
13 Arrester; 3-Pole MOV,600V WYE X13641454001 1
