Trane IntelliPak 1 User Manual

RT-SVX072A-EN
101
Table 45. Return fan performance—40, 50 and 55 ton air-cooled and (27" Fan) (continued)
CFM
Std
Air
Return Fan Static Pressure Including Relief Damper P.D.
0.25 0.50 0.75 1.00 1.25 1.50 1.75 2.00
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
20000 1738 10.30 1765 11.13 1790 11.97 1816 12.83 1840 13.69 1864 14.56 1888 15.46 1910 16.34
20500 1780 11.05 1806 11.90 1831 12.76 1856 13.63 1880 14.52 1903 15.41 1926 16.31 1949 17.22
21000 1822 11.84 1848 12.71 1872 13.59 1897 14.48 1920 15.39 1943 16.29 1966 17.23 1988 18.14
21500 1864 12.66 1889 13.55 1914 14.45 1937 15.36 1960 16.29 1983 17.22 2005 18.16 2027 19.11
22000 1899 13.05 1926 14.11 1952 15.16 1977 16.20 2001 17.23 2024 18.24 2047 19.27 2069 20.28
22500 1941 13.91 1967 14.98 1992 16.05 2017 17.12 2041 18.19 2064 19.23 2086 20.27 2108 21.31
Notes:
1. Max fan RPM 1981 For 27" Class II Fan
2. Max Motor Available 15 HP For 27" Fan Size
3. Max motors Available are as follows: 40/48T: 10 HP & 50-55/59T: 15 HP
4. Max CFM is as follows: 40/48T: 18000, 50-55/59T: 22500
5. Min CFM is as follows: 40/48T: 7500, 50-55/59T: 9000
6. Return fan belt drive RPM selections will be available to cover 700-1900 RPM range +/- 50 RPM
7. Performance data includes cabinet and rain hood effect. Damper pressure drop must be added to the return duct static. See table Component static
pressure drops - relief damper for return fan in Performance Data.
8. Shaded area indicates nonstandard BHP or RPM selections. Contact a local Trane® representative for more information.
Table 46. Return fan performance—60 to 75 tons air-cooled and (36.5" fan)
CFM
Std
Air
Return Fan Static Pressure Including Relief Damper P.D.
0.25 0.50 0.75 1.00 1.25 1.50 1.75 2.00
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
12000 459 1.07 502 1.59 541 2.13 578 2.71 613 3.31 647 3.91 681 4.54 713 5.20
13000 490 1.27 530 1.83 567 2.40 603 3.01 636 3.65 668 4.29 700 4.94 731 5.64
14000 520 1.49 560 2.09 595 2.70 628 3.34 660 3.99 691 4.69 721 5.38 751 6.10
15000 552 1.73 590 2.38 623 3.03 655 3.70 686 4.39 715 5.11 744 5.85 771 6.59
16000 583 2.00 619 2.70 652 3.39 682 4.09 712 4.82 740 5.57 767 6.34 794 7.14
17000 615 2.30 650 3.05 681 3.78 710 4.52 739 5.28 766 6.06 792 6.85 818 7.67
18000 646 2.64 680 3.43 711 4.20 739 4.98 766 5.78 792 6.60 817 7.41 842 8.27
19000 678 3.01 711 3.85 741 4.67 768 5.48 794 6.31 819 7.16 844 8.03 867 8.89
20000 711 3.42 742 4.30 771 5.17 797 6.02 823 6.90 847 7.77 871 8.66 894 9.59
21000 743 3.87 773 4.78 801 5.70 827 6.60 852 7.51 875 8.41 898 9.36 920 10.30
22000 775 4.36 805 5.31 832 6.28 857 7.22 881 8.17 904 9.11 926 10.09 947 11.06
23000 808 4.89 836 5.88 863 6.90 887 7.89 911 8.88 933 9.87 954 10.86 975 11.88
24000 840 5.46 868 6.49 894 7.56 918 8.60 941 9.63 962 10.67 983 11.71 1004 12.75
25000 873 6.08 900 7.15 925 8.26 948 9.35 970 10.42 992 11.49 1012 12.59 1032 13.67
26000 906 6.75 931 7.86 956 9.00 979 10.16 1001 11.28 1021 12.37 1041 13.49 1061 14.63
27000 939 7.47 963 8.62 987 9.79 1010 11.01 1031 12.18 1052 13.33 1071 14.47 1090 15.65
Notes:
1. Max fan RPM 1151 for 36.5" Class I Fan
2. Max motor available 20 HP for 36.5" fan size
3. Max motor available 20 HP for 60/73, 70/80 & 75/89T
4. Max CFM is 27000 for 60/73, 70/80 & 75/89T
5. Min CFM is 12000 for 60/73, 70/80 & 75/89
6. Return fan belt drive RPM selections will be available to cover 500-1100 RPM range +/- 50 RPM
7. Performance data includes cabinet and rain hood effect. Damper pressure drop must be added to the return duct static. See table Component static
pressure drops - relief damper for return fan in Performance Data.
UUnniitt SSttaarrttuupp
