Service Sizing Data
Table 20. Compressor electrical service sizing data (20 to 130 tons)
Tonnage
No. of
Compres-
sors
200 V 230 V 460 V 575 V
RLA/MRC
(a)
LRA
(ea.)
RLA/MRC
(a)
LRA
(ea.)
RLA/MRC
(a)
LRA
(ea.)
RLA/MRC
(a)
LRA
(ea.)
(ea.) (ea.) (ea.) (ea.)
20 Standard
1 52.8 300 52.8 300 23.8 150 20.5 109
1 33.5 240 33.5 240 15.3 130 11.4 94
20 High
Efficiency
1 52.8 300 52.8 300 23.8 150 20.5 109
1 33.5 240 33.5 240 15.3 130 11.4 94
20 Variable
Speed
1
(b)
34.3
N/A
29.9
N/A
14.9
N/A
12.5
N/A
1 36.8 267 32.0 267 16.0 142 15.2 103
25 Standard
1 27.7 203 27.7 203 14.5 98 12.5 84
2 36.8 267 32.0 267 16.0 142 15.2 103
25 High
Efficiency
1 57.8 340 57.4 340 27.1 179 24.4 132
1 37.1 240 36.4 240 17.0 140 13.3 108
25 Variable
Speed
1
(b)
38.6
N/A
33.6
N/A
23.1
N/A
14.1
N/A
1 40.3 267 40.3 267 19.1 142 15.8 103
30 Standard
1 27.7 203 27.7 203 14.5 98 12.5 84
2 40.3 267 40.3 267 19.1 142 15.8 103
30 High
Efficiency
1 27.7 203 27.7 203 14.5 98 12.5 84
2 40.3 267 40.3 267 19.1 142 15.8 103
30 Variable
Speed
1
(b)
52.3
N/A
45.5
N/A
22.7
N/A
19.1
N/A
1 51.3 315 45.6 315 22.3 158 19.1 136
40 Standard
1 30.6 203 28.4 203 13.3 98 11.9 84
3 36.8 267 32.0 267 16.0 142 15.2 103
40 High
Efficiency
2 30.6 203 28.4 203 13.3 98 11.9 84
2 36.8 267 32.0 267 16.0 142 15.2 103
40 Variable
Speed
1
(b)
52.3
N/A
45.5
N/A
24.6
N/A
19.1
N/A
2 36.8 267 32.0 267 16.0 142 15.2 103
50 Standard 4 40.3 267 40.3 267 19.1 142 15.8 103
50 High
Efficiency
2 40.3 267 40.3 267 19.1 142 15.8 103
2 46.2 304 42.3 304 20.1 147 17.2 122
50 Variable
Speed
1
(b)
85.9
N/A
74.7
N/A
39.6
N/A
32.3
N/A
2 46.2 304 42.3 304 20.1 147 17.2 122
55 Standard
2 46.2 304 42.3 304 20.1 147 17.2 122
2 51.3 315 45.6 315 22.3 158 19.1 136
55 High
Efficiency
4 46.2 304 42.3 304 20.1 147 17.2 122
55 Variable
Speed
1
(b)
85.9
N/A
74.7
N/A
39.6
N/A
32.3
N/A
1 46.2 304 42.3 304 20.1 147 17.2 122
1 51.3 315 45.6 315 22.3 158 19.1 136
60 Standard 4 51.3 315 45.6 315 22.3 158 19.1 136
60 High
Efficiency
3 51.3 315 45.6 315 22.3 158 19.1 136
1 59.8 345 52.0 345 26.0 155 23.1 126
60 Variable
Speed
1
(b)
84.8
N/A
73.7
N/A
39.6
N/A
31.9
N/A
1 51.3 315 45.6 315 22.3 158 19.1 136
1 59.8 345 52.0 345 26.0 155 23.1 126
70 Standard
2 59.8 345 52.0 345 26.0 155 23.1 126
1 59.6 320 51.8 320 25.9 160 20.7 135
1 77.4 485 69.3 485 33.7 215 27.1 175
70 High
Efficiency
4 59.8 345 52.0 345 26.0 155 23.1 126
70 Variable
Speed
1
(b)
96.2
N/A
78.7
N/A
45.0
N/A
36.2
N/A
1 59.6 320 51.8 320 25.9 160 20.7 135
1 77.4 485 69.3 485 33.7 215 27.1 175
75 Standard
2 59.6 320 51.8 320 25.9 160 20.7 135
2 77.4 485 69.3 485 33.7 215 27.1 175
75 High
Efficiency
1 59.6 320 51.8 320 25.9 160 20.7 135
3 77.4 485 69.3 485 33.7 215 27.1 175
