Trane IntelliPak 1 User Manual

RT-SVX072A-EN
99
Table 40. 100% Relief fan drive selections — 20 to 75 tons (continued)
3 Hp 5 Hp 7.5 Hp 10 Hp 15 Hp 20 Hp
RPM
Drive
No.
RPM
Drive
No.
RPM
Drive
No.
RPM
Drive
No.
RPM
Drive
No.
RPM
Drive
No.
60 400 4 600 6 600 6 700 7 800 8
70 500 5 700 7 700 7 800 8
75 600 6
Table 41. 100% Relief fan drive selections — 90 to 130 tons
Nom
Tons
15 HP 20 HP 25 HP 30 HP 40 HP
RPM
Drive
No.
RPM
Drive
No.
RPM
Drive
No.
RPM
Drive
No.
RPM
Drive
No.
90-130
500 5 500.00 5 600.00 6 600.00 6 700.00 7
600 6 600.00 6 700.00 7 700.00 7 800.00 8
700 7 800 8 800 8
Table 42. 50% Relief fan performance — 90 to 130 tons
Nom
Tons
CFM
Std
Air
Negative Static Pressure
0.25 0.50 0.75 1.00 1.25
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
90-
130
12000 432 4.09 461 4.31 502 4.86 545 5.67 585 6.35
14000 495 6.40 519 6.65 547 6.96 582 7.64 619 8.57
16000 559 9.46 581 9.77 602 10.02 628 10.45 658 11.20
18000 623 13.36 643 13.73 662 14.05 680 14.31 705 14.83
20000 688 18.23 707 18.66 724 19.03 741 19.36 757 19.65
Nom
Tons
CFM
Std
Air
Negative Static Pressure
1.50 1.75 2.00 2.25 2.50
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
90-
130
12000 622 7.19 655 7.99 686 8.78 717 9.57 748 10.48
14000 655 9.42 689 10.26 721 11.26 750 12.21 777 13.14
16000 690 12.19 723 13.32 753 14.22 784 15.18 811 16.27
18000 732 15.63 759 16.65 788 17.88 817 19.13 844 20.12
20000 779 20.22 804 21.04 827 22.07 853 23.31 879 24.70
Notes:
1. Shaded areas indicate non-standard drive selections. These drive selections must
be manually factory selected.
2. Refer to General Data Table for minimum and maximum HP.
Table 43. 50% Relief fan drive selections, 90 to 130 tons
Nom Tons
15 Hp
RPM Drive No.
90-130
500 5
600 6
700 7
800 8
900 9
UUnniitt SSttaarrttuupp
