Page #102 background imageLoading...
Page #102 background image
102 RT-SVP04F-EN
System Configuration
Configuration - Model Num Digit 5, 6, 7
Unit Capacity: 90
Used With: Rooftop Units and Air
Handlers with DX Cooling
Possible Values: 20-162 Tons
OR
Configuration - Model Num Digit 5, 6, 7
Unit Capacity CFM: 16100-45000
Used With: Screen shown only for RT
AH units with None or Chilled Water
Cooling
Possible Values: CONFIG REQ’D,
4000-45000
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
Configuration - Model Num Digit 6
Cooling Type: NO COOLING
Used With: Screen shown only if Air
Handler Unit
Possible Values: CONFIG REQ’D, No
Cooling, DX Cooling, Chilled Water
OR
Configuration - Model Num Digit 9
Electric Heat Capacity: 90 KW
Used With: Units with Electric Heat
installed
Possible Values: Not CONFIG,
CONFIG, 30, 50, 70, 110, 130, 150,
170, 190 kW
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
OR
Configuration - Model Num Digit 9
Gas Heat Type: STAGED
Used With: Screen shown only if Gas
Heat installed
Possible Values: Staged, Modulating
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
Configuration - Model Num Digit 17 or 11
Exhaust/Return: NONE
Used With: All Units
Possible Values: CONFIG REQ’D,
None, EXH FAN_W/ STATITRAC, EXH
FAN_W/O STATITRAC, RET FAN W/
STATITRAC, RET FAN W/O STATITRAC
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
Note: Return Fan selection not permitted to be installed if
Energy Recovery option is already installed.
Configuration - Model Num Digit 20 or 17
System Control: ZONE TEMP CTRL (CV)
Used With: All Units
Possible Values: CONFIG REQ'D,
ZONE TEMP CTRL (CV), DISCH TEMP
CTRL (VAV), DISCH TEMP CTRL (CV)
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
