RT-SVP04F-EN 103
System Configuration
Note: For DISCH TEMP CTRL (VAV) possible value, this indicates with IGV/VFD.
Note: For DISCH TEMP CTRL (CV) possible value, this indicates without IGV/VFD.
Configuration - Model Num Digit 21 or 16
Fresh Air Section: No Fresh Air
Used With: All Units
Possible Values: CONFIG REQ'D, NO
FRESH AIR, 0-100% ECONOMIZER, 0-
25% MOTORIZED DAMPER
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
Configuration - Model Num Digit 21 or 31
Ventilation Ctrl (VCM) CONFIG REQ'D
Used With: All Units
Possible Values:
* Ventilation Ctrl (VCM) CONFIG REQ'D,
* Ventilation Ctrl (VCM) NOT INSTALLED
* Fresh Air Measurement(VCM) W/ DCV
OPTION
* OA Damper Min Pos (VCM) W/ DCV
OPTION
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
Note: For Ventilation Ctrl (VCM) NOT INSTALLED possible value, this screen used to indicate
Ventilation Ctrl module NOT INSTALLED. There are two possible VCM "installed" options.
Configuration - Model Num Digit 21 or 23
Comparative Enthalpy: INSTALLED
Used With: Screen always shown
Possible Values: CONFIG REQ'D, NOT
INSTALLED, INSTALLED
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
Configuration - Model Num Digit 24
Final Filters: INSTALLED
Used With: All IntelliPak II Units
Possible Values:CONFIG REQ'D, NOT
INSTALLED, INSTALLED
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
Configuration - Model Num Digit 25
Energy Recovery: NOT INSTALLED
Used With: All IntelliPak II Units with
Energy Recovery installed
Possible Values: CONFIG REQ'D, NOT
INSTALLED, INSTALLED W/O PREHEAT,
INSTALLED W/ PREHEAT
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
Note: This feature not permitted to be installed if Return Fan is already installed.
