104 RT-SVP04F-EN
System Configuration
Configuration - Model Num Digit 27
Condenser Type: Air-Cooled
Used With: All IntelliPak II Units
Possible Values: CONFIG REQ'D, AIR-
COOLED, WATER-COOLED W/O SUMP
HT, WATER-COOLED WITH SUMP HT
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
Note: For WATER-COOLED possible values the unit must be physically configured with water-cooled
condensers or improper operation and possible unit damage may occur.
Configuration - Model Num Digit 30 or 22
Dehumid w/ Hot Gas Reheat: NOT INSTALLED
Used With: All IntelliPak Units
Possible Values:
NOT INSTALLED, INSTALLED
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
Note: This feature uses a hardware configuration jumper and is not HI adjustable.
Configuration - Model Num Digit 30 or 22
Hot Gas Bypass: INSTALLED
Used With: All Units
Possible Values: CONFIG REQ’D, NOT
INSTALLED, INSTALLED
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
Note: If Hot Gas Bypass is installed Low Charge Protection and
Lead/Lag functions will be automatically disabled.
Configuration - Model Num Digit 31 or 19
Ambient Control: STANDARD
Used With: All Units
Possible Values: CONFIG REQ’D,
STANDARD, 0 DEGREE F
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
Note: When set to "STANDARD" the Low Abient Compressor
Lockout setpoint may not be set less than 40 F. When set
to "0 DEGREE F" the setpoint can be set down to -20 F.
Configuration - Model Num Digit 33 or 30
Remote Human Interface INSTALLED
Used With: All Units
Possible Values: CONFIG REQ’D, NOT
INSTALLED, INSTALLED
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
