RT-SVP04F-EN 11 3
System Testing & Troubleshooting
Relay State = HEAT ON Used With: Air Handlers with
Chilled Water Cooling and
Modulating Gas Heat installed.
Possible Values: Relay State=
HEAT ON, COOL ON; 0-100%
Mod Gas Heat/Chilled Water Output 0%
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key to advance the cursor.
4. Repeat steps 1 and 2 for the next value.
5. Press the NEXT key until the following screen is displayed
(if applicable).
CHILLED WATERUsed With: Air Handlers with
Chilled Water Cooling and Heat type
is not Hydronic or Mod Gas Heat.
Possible Values: 0-100%
Actuator 0%
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key to advance the cursor.
4. Repeat steps 1 and 2 for the next value.
5. Press the NEXT key until the following screen is displayed
(if applicable).
Hydronic Heat Used With: All Rooftop Units when
Hydronic heat is installed and Air
Handlers when DX Cooling is
installed
Factory Presets:
0%
Possible Values: 0 - 100%
Actuator 0%
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice
3. Press the NEXT key until the following screen is displayed.
Modulating Gas Heat Used With: All Rooftop Units when
Modulating Gas is installed and Air
Handlers when DX Cooling is
installed
Factory Presets:
0%
Possible Values: 0 - 100%
Actuator 0%
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice
3. Press the NEXT key until the following screen is displayed.
Heat Stages: 0 Used With: All Units when Staged
Gas Heat or electric Heat is installed
Factory Presets:
OFF
Possible Values: OFF, ON, Heat
Stages: 0-6
K11: OFF K12: OFF K1: OFF
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice
3. Press the NEXT key until the following screen is displayed.
