146 RT-SVP04F-EN
System Testing & Troubleshooting
Generic BAS Module
10V
There are 4 analog
inputs. Each input
can be configured as
one of the
following definitions: the
inputs 1, 2, 3,
& 4 may be assigned to:
Occupied Zone Cooling
SETPOINT, Occupied
Zone, Heating
SETPOINT, Unoccupied
Zone, Cooling
SETPOINT, Unoccupied
Zone, Heating
SETPOINT, Space Static,
Pressure SETPOINT, or
Minimum OA Flow
SETPOINT.
No 2 inputs can be
assigned to the same
definition.
• Address
• There are 4 analog
outputs--each output
can be configured as
defined in GBAS Analog
output assignments.
• GBAS Demand Limit
Input
Active Diagnostic
Output
Heat Module • Morning Warmup
Temperature Sensor
• Address
• Modulating Heat
Actuator
(Hydronic)
• HW Freeze Status -
Heat Fail
• CW Freeze Status
• Heat 1 (K1) Relay
• Heat 2 (K2) Relay
• Heat 3 (K3) Relay
Human Interface
Module
• None • None • None • None
Interprocessor
Communications
Bridge (IPCB) Module
• None • None • None • None
Multi-Purpose Module • Return Air Plenum
Pressure
• Liquid Line Pressure
Ckt 1
• Liquid Line Pressure
Ckt 2
• Address
• Outdoor Air Bypass
Damper
• Exhaust Air Bypass
Damper/Return Fan
Speed
• Energy Recovery
Preheat
• Dirty Recovery Filter • Energy Recovery
Wheel
• Return Air Plenum
Pressure Calibration
• Energy Recovery
Preheat
VCM • Front Velocity Pressure
Transduc er
• Back Velocity Pressure
Transduc er
• Auxiliary Temperature
• Space CO
2
Sensor
• Address
• Outside Air CFM (PCB
Only)
• None • Preheater Relay
• Pressure Calibration
MDM • Reheat Valve Output
(Phase A & B)
• Cooling Valve Output
(Phase A & B)
• Reheat Pumpout Relay
UNIT MODULE ANALOG INPUTS ANALOG OUTPUTS BINARY INPUTS BINARY OUTPUTS
