RT-SVP04F-EN 145
System Testing & Troubleshooting
Rooftop Module • Zone Temperature
Sensor
• S/A Temperature
Sensor
• O/A Temperature
Sensor
• Mode Input Channel
(from the remote
panel)
• Cooling SETPOINT
(from the remote
panel)
• Heating SETPOINT
(from the remote panel)
• Supply Air Pressure
Transduc er
• Outdoor Air Humidity
Sensor
• Auxiliary Temperature
Sensor
• Economizer Minimum
Position
• Space Humidity
Sensor
• Address
• Outside Air Damper
Output
• IGV/VFD Outputs
• Emergency Stop
• Dehumidification
Configuration Input
• External Auto/Stop
• Occupied/Unoccupied
• Supply Airflow Proof
• Dirty Filter
• VAV Changeover
• IntelliPak II
configuration Input
• Dirty Final Filter
• Exhaust/Return
Airflow
• Occupied/Unoccupied
Relay
• Alarm Relay
• Supply Fan Relay
• LED 1-4 Transistor
• Exhaust/return Fan
Relay
• Humidification Relay
Ventilation Override
Module
• Address • None • VOM Mode A Contacts
• VOM Mode B Contacts
• VOM Mode C Contacts
• VOM Mode D Contacts
• VOM Mode E Contacts
• VOM Relay
Exhaust/Comparative
Enthalpy Module
(ECEM)
• Return Air
Temperature Sensor
• Return Air Humidity
Sensor
• Space Pressure
• Address
• Exhaust Fan Speed-
Damper
• None • Space Pressure
Calibration Solenoid
Generic BAS Module
5V
There are 4 analog
inputs. Each input can
be configured as one of
the following definitions:
the inputs 1, 2, 3, & 4
may be assigned to:
Occupied Zone Cooling
SETPOINT, Occupied
Zone, Heating
SETPOINT, Unoccupied
Zone, Cooling
SETPOINT, Unoccupied
Zone, Heating
SETPOINT, Space Static,
Pressure SETPOINT, or
Minimum OA Flow
SETPOINT. No 2 inputs
can be assigned to the
same definition.
• Address
• None • GBAS Demand Limit
Input
• GBAS Binary Output 5
• GBAS Binary Output 4
• GBAS Binary Output 3
• GBAS Binary Output 2
• GBAS Binary Output 1
UNIT MODULE ANALOG INPUTS ANALOG OUTPUTS BINARY INPUTS BINARY OUTPUTS
