General Information
Supply Fan IGV/VFD (if equipped)
Actuator SETUP Direct Acting SETUP
Max Stroke Time 30 sec SETUP
Max Voltage 10 VDC SETUP
Min Voltage 2 VDC SETUP
Exhaust Damper/VFD (if equipped)
Actuator SETUP Direct Acting SETUP
Max Stroke Time 60 sec SETUP
Max Voltage 10 VDC SETUP
Min Voltage 0 VDC SETUP
Return Fan VFD (if equipped)
Actuator SETUP Direct Acting SETUP
Max Stroke Time 60 sec SETUP
Max Voltage 10 VDC SETUP
Min Voltage 2 VDC SETUP
Exhaust bypass damper
Actuator SETUP Direct Acting SETUP
Max Stroke Time 60 sec SETUP
Max Voltage 10 VDC SETUP
Min Voltage 2 VDC SETUP
Outdoor air bypass damper
Actuator SETUP Direct Acting SETUP
Max Stroke Time 60 sec SETUP
Max Voltage 10 VDC SETUP
Min Voltage 2 VDC SETUP
Modulating Gas Heat Actuator (if equipped)
Actuator SETUP... (Direct/reverse action) Direct
2
/Reverse
1
Acting
SETUP
Max stroke time 90 seconds SETUP
Max voltage 10 VDC SETUP
Min voltage 2 VDC
2
/5 VDC
1
SETUP
Head Pressure Control
Temporary low limit suppression 10 deg F SETUP
Upper limit 120 deg F SETUP
Low limit 80 deg F SETUP
Efficiency check point 105 deg F SETUP
Low ambient control point 90 deg F SETUP
Sump Drain Relay Control (on power loss)
2
Drain SETUP
Sump Purge Interval Time
2
3 hours SETUP
