Trane IntelliPak I User Manual

RT-SVP04F-EN 21
General Information
Occupied zone heating Default SETUP
Space Pressure Default SETUP
Unoccupied zone cooling Default SETUP
Unoccupied zone heating Default SETUP
Economizer Dry Bulb Enable Default SETUP
Occupied Dehumidification Default SETUP
Unoccupied Dehumidification Default SETUP
Supply Air Reheat Default SETUP
OA Damper Actuator (if equipped)
Actuator SETUP DIRECT SETUP
Max stroke time 30 sec SETUP
Max voltage 10 VDC SETUP
Min voltage 2 VDC SETUP
Exhaust Damper Actuator (if equipped)
Actuator SETUP... (Direct/reverse action) DIRECT SETUP
Max stroke time 30 sec SETUP
Max voltage 10 VDC SETUP
Min voltage 2 VDC SETUP
Adjustable Function
Factory
Preset Changed To
To adjust
Press...
Hydronic Heat Actuator (if equipped)
Actuator SETUP... (Direct/reverse action) Direct Acting SETUP
(Max stroke time) 60 seconds SETUP
(Max voltage) 10 VDC SETUP
(Min voltage) 2 VDC SETUP
Lo Ambient Damper Actuator Ckt#1 and Ckt #2
(if equipped)
Actuator SETUP... (Direct/reverse action) Direct Acting SETUP
(Max stroke time) 60 seconds SETUP
(Max voltage) 10 VDC SETUP
(Min voltage) 2 VDC SETUP
Cond Fan VFD Ckt #1
Actuator SETUP Direct Acting SETUP
Max Stroke Time 60 sec SETUP
Max Voltage 10 VDC SETUP
Min Voltage 0 VDC SETUP
Cond Fan VFD Ckt #2
Actuator SETUP Direct Acting SETUP
Max Stroke Time 60 sec SETUP
Max Voltage 10 VDC SETUP
Min Voltage 0 VDC SETUP
