Trane IntelliPak I User Manual

20 RT-SVP04F-EN
General Information
Design Min CO
2
(DCV) 1000 PPM SETPOINTS
DCV Min CO
2
800
1
/400
2
PPM SETPOINTS
DCV Min OA Flow Deadband 5 CCFM SETPOINTS
Design Min OA Flow (DCV) 220 CCFM SETPOINTS
DCV Min OA Flow 67 CCFM SETPOINTS
Design Min OA Damper Position(DCV) 15% SETPOINTS
DCV Min OA Damper Position 5% SETPOINTS
OA Damper Min Position (non-DCV) 15% SETPOINTS
Hydronic Heat Freeze Avoidance Open To: 0% SETPOINTS
Recovery Frost Avoidance Setpoint 27F SETPOINTS
Functions enable/disable
Compressor lead/lag Enable SETUP
Adjustable Function
Factory
Preset Changed To
To adjust
Press...
Morning warmup Enable SETUP
Supply air tempering Enable SETUP
Unoccupied economizer Enable SETUP
Unoccupied mechanical cooling Enable SETUP
Unoccupied heating Enable SETUP
Occupied Dehumidification Enable SETUP
Unoccupied Dehumidification Enable SETUP
Demand Control Ventilation Disable SETUP
Occupied Humidification Disable SETUP
Unoccupied Humidification Disable SETUP
GBAS Input/Output Definitions...
GBAS analog input definitions Not Assigned SETUP
GBAS output definitions SETUP
Information format
Text displays English SETUP
Unit displays English SETUP
RTM alarm output definitions Any Active Diagnostic SETUP
Sensor source selection for...
Monitor RTM Zone Temp SETUP
Morning warmup RTM Zone Temp SETUP
Occupied zone control RTM Zone Temp SETUP
Unoccupied zone control RTM Zone Temp SETUP
Space Humidity Control RTM Space Humidity SETUP
Dehumid OVRD Zone Temp RTM Zone Temp SETUP
SETPOINT source selection for...
Morning warmup Default SETUP
Occupied zone cooling Default SETUP
