Trane PIC - Data Point List for CGAN;CXAN (Tracer CH532 V1.2)

Operation
BAS-SVX08D-E428
Table 10 - Data Point List for CGAN/CXAN chillers,Tracer CH532 controller Version 1.2
Data Type Function Modbus Index Offset Point Description Unit
Binary
Outputs
5/15
00001 0 Chiller Enable/Disable Command (0=Disable) bit
00002 1 Chiller Mode (0=Cool) bit
00003 2 Circuit 1 lockout bit
00004 3 Circuit 2 lockout bit
Analog
Outputs
6/16
40001 0 Copy of function 5/15 binary points bitfield
40002 1 Chilled Water Setpoint Temperature
40003 2 Heating Setpoint Temperature
Binary Inputs 2
10002 1 Chiller Running Status bit
10003 2 Circuit 1 Fan 1 output bit
10004 3 Circuit 1 Fan 2 output bit
10008 7 Compressor A1 output bit
10009 8 Compressor B1C1 output bit
10010 9 Compressor A2 output bit
10011 10 Compressor B2C2 output bit
Analog Inputs 4
30001 0 Copy of function 2 binary points bitfield
30002 1 Active Chilled/Hot Water Setpoint Temperature
30003 2 Evaporator Leaving Water Temperature Temperature
30004 3 Evaporator Entering Water Temperature Temperature
30005 4 Condenser Entering Water Temperature Temperature
30006 5 Chiller Status (See Appendix) bitfield
