Trane PIC - Appendix

Appendix
77BAS-SVX08D-E4
Table B - How to read Compressor Running Outputs in equipment data point lists
Table C - How to read Condenser Fan Running Outputs in equipment data point lists
Condenser Fan Running Outputs - bitfield
Bit Position Description
Bit 15 Condenser fan(s) H On (1=On)
Bit 14 Condenser fan(s) G On (1=On)
Bit 13 Condenser fan(s) F On (1=On)
Bit 12 Condenser fan(s) E On (1=On)
Bit 11 Condenser fan(s) D On (1=On)
Bit 10 Condenser fan(s) C On (1=On)
Bit 9 Condenser fan(s) B On (1=On)
Bit 8 Condenser fan(s) A On (1=On)
Bit 7 Condenser fan(s) H exists (1=Yes)
Bit 6 Condenser fan(s) G exists (1=Yes)
Bit 5 Condenser fan(s) F exists (1=Yes)
Bit 4 Condenser fan(s) E exists (1=Yes)
Bit 3 Condenser fan(s) D exists (1=Yes)
Bit 2 Condenser fan(s) C exists (1=Yes)
Bit 1 Condenser fan(s) B exists (1=Yes)
Bit 0 Condenser fan(s) A exists (1=Yes)
Compressor Running Outputs - bitfield
Bit Position Description
Bit 15 Not used
Bit 14 Not used
Bit 13 Compressor F running (1=On)
Bit 12 Compressor E running (1=On)
Bit 11 Compressor D running (1=On)
Bit 10 Compressor C running (1=On)
Bit 9 Compressor B running (1=On)
Bit 8 Compressor A running (1=On)
Bit 7 Not used
Bit 6 Not used
Bit 5 Compressor F exists (1=Yes)
Bit 4 Compressor E exists (1=Yes)
Bit 3 Compressor D exists (1=Yes)
Bit 2 Compressor C exists (1=Yes)
Bit 1 Compressor B exists (1=Yes)
Bit 0 Compressor A exists (1=Yes)
