Operation
BAS-SVX08D-E434
Table 14 - Data Point List for RTAA/RTAB/RTXA/RTAD/RTWB/RTRA/RTUB chillers, UCM CLD controller with CSR
Data
Type
Offset Point DescriptionFunction
Modbus
Index
00001 0 Enable remote setpoints bit
00002 1 Remote chiller auto/stop (0 = auto, 1 = stop) bit
00003 2 Enable Hot water setpoint bit
00004 3 Ice mode (1 = yes, 0 = no) bit
00005 4 Not used bit
00006 5 Lock out circuit 1 (1 = yes, 0 = no) bit
00007 6 Lock out circuit 2 (1 = yes, 0 = no) bit
00012 11 External hot water setpoint (1 = enable) bit
00013 12 RTXA unit type (1 = RTXA, 0 = other) bit
00014 13 RTUA unit type (1 = RTUA, 0 = other) bit
40001 0 Remote chilled water setpoint Temperature
40002 1 Remote current limit setpoint Percentage
40003 2 Copy of function 5/15 binary points bitfield
40004 3 Front panel hot water setpoint Temperature
40005 4 Front panel heating design delta temp Temperature
10001 0 Compressor running bit (1 = any compressor running) bit
10004 3 Machine manual reset required (1 = active) bit
10005 4 Machine auto reset (1 = active) bit
10007 6 Compressor contactor 1 ( 1 = ON, 0 = OFF) bit
10008 7 Compressor contactor 1 ( 1 = ON, 0 = OFF) bit
10009 8 Compressor contactor 2 ( 1 = ON, 0 = OFF) bit
10010 9 Compressor contactor 2 ( 1 = ON, 0 = OFF) bit
10011 10 Unit heat/cool mode (1 = heat, 0 = cool) bit
10018 17 Remote setpoints valid (1 = Yes, 0 = No) bit
10019 18 UCM communication established (1 = Yes, 0 = No) bit
10020 19 Fan control (1 = enabled, 0 = disabled) bit
10021 20 SI display units (1 = enabled, 0 = disabled) bit
10022 21 Under/over voltage detection (1 = enabled, 0 = disabled) bit
10023 22 Phase unbalance protection (1 = enabled, 0 = disabled) bit
10024 23 Phase reversal protection (1 = enabled, 0 = disabled) bit
10025 24 Night noise setback (1 = enabled, 0 = disabled) bit
10026 25 Reduced intrush starting (1 = enabled, 0 = disabled) bit
10027 26 Lead/lag (1 = enabled, 0 = disabled) bit
10028 27 Reset relay 1 ( 1 = ON, 0 = OFF) bit
10029 28 Condenser fan contactor 4 ( 1 = ON, 0 = OFF) bit
10030 29 Condenser fan contactor 3 ( 1 = ON, 0 = OFF) bit
10031 30 Condenser fan contactor 2 ( 1 = ON, 0 = OFF) bit
10032 31 Condenser fan contactor 1 ( 1 = ON, 0 = OFF) bit
10033 32 Oil line solenoid valve 1,
female slide valve step load solenoid for 70-125 Ton ( 1 = ON, 0 = OFF) bit
10034 33 Transition contactor 1 ( 1 = ON, 0 = OFF) bit
10035 34 Reset relay 1 ( 1 = ON, 0 = OFF) bit
10036 35 Condenser fan contactor 4 ( 1 = ON, 0 = OFF) bit
10037 36 Condenser fan contactor 3 ( 1 = ON, 0 = OFF) bit
10038 37 Condenser fan contactor 2 ( 1 = ON, 0 = OFF) bit
10039 38 Condenser fan contactor 1 ( 1 = ON, 0 = OFF) bit
10040 39 Oil line solenoid valve 1,
female slide valve step load solenoid for 70-125 Ton ( 1 = ON, 0 = OFF) bit
Binary
Outputs
5/15
Analog
Outputs
6/16
Binary
Inputs
2
Unit
To Next Page
