Operation
43BAS-SVX08D-E4
Table 16 - Data Point List for Rooftops, UCP2/UCP3 and Reliatel controllers
Data
Type
Offset Point DescriptionFunction
Modbus
Index
00001 0 ICS Diagnostic Reset (1 = Yes 0 = No) bit
00002 1 Factory Test (*** Factory Use Only ***) (1 = Yes 0 = No) bit
00003 2 ICS Slave Mode Requested (1 = Yes 0 = No) bit
00004 3 Unit Control Source (1 = ICS 0 = Local) bit
00005 4 Supply Fan Mode (1 = On (Continuous) 0 = Auto) bit
00006 5 Econ Drive Open (1 = Drive Open 0 = Auto) bit
00007 6 Econ Drive Closed (1 = Drive Closed 0 = Auto) bit
00008 7 Econ Drive to Min Pos (1 = Drive to Min Position 0 = Auto) bit
Economizer Control (bits 00009 00010)
0 0 Economizer Disabled
00009-00010 8-9 0 1 Economizer Disabled
1 0 Use Local Economizer Enthalpy Request (AUTO)
1 1 Override Local Economizer Enthalpy Request (ENABLED) bit
00011 10 ICS Manual Heat/Cool Override (1 = Manual 0 = Auto) bit
00012 11 ICS Manual Override Selection (1 = Cool 0 = Heat) bit
00013 12 ICS Unit Stop Request (1 = Off 0 = Auto) bit
00014 13 Supply Air Tempering Request (1 = Enable 0 = Disable) bit
00015 14 Emergency Heat Mode Req (Heat Pump Only) (1 = Em Heat 0 = Auto) bit
00016 15 Emergency Stop Request (1 = Yes 0 = No) bit
00017 16 Auxiliary Heat Lockout (1 = Not Locked Out 0 = Lock Out) bit
00018 17 Compressor Lockout (Lockout Both) (1 = Not Locked Out 0 = Lock Out) bit
40001 0 Slave State Number ( 0 to 10 and 12) None
40002 1 Economizer Damper Minimum Position ( 0 to 50 %) Percentage
40003 2 ICS Zone Cooling Setpoint Temperature
40004 3 ICS Zone Heating Setpoint Temperature
40005 4 Number of Cooling Stages to be Enabled ( 0 to 3 ) None
40006 5 Number of Heating Stages to be Enabled ( 0 to 3 ) None
Bit 0 Econ Drive to Min Pos (1 = Drive to Min Position 0 = Auto)
Bit 1 Econ Drive Closed (1 = Drive Closed 0 = Auto)
Bit 2 Econ Drive Open (1 = Drive Open 0 = Auto)
40007 6 Bit 3 Supply Fan Mode (1 = On (Continuous) 0 = Auto)
Bit 4 Unit Control Source (1 = ICS 0 = Local)
Bit 5 ICS Slave Mode Requested (1 = Yes 0 = No)
Bit 6 Factory Test (*** Factory Use Only ***) (1 = Yes 0 = No)
Bit 7 ICS Diagnostic Reset (1 = Yes 0 = No) bitfield
Bit 0 Emergency Stop Request (1 = Yes 0 = No)
Bit 1 Emergency Heat Mode Req (Heat Pump Only) (1 = Em Heat 0 = Auto)
Bit 2 Supply Air Tempering Request (1 = Enable 0 = Disable)
Bit 3 ICS Unit Stop Request (1 = Off 0 = Auto)
Bit 4 ICS Manual Override Selection (1 = Cool 0 = Heat)
40008 7 Bit 5 ICS Manual Heat/Cool Override (1 = Manual 0 = Auto)
Bit 6, 7 Economizer Control (bits 7 6)
0 0 Economizer Disabled
0 1 Economizer Disabled
1 0 Use Local Economizer Enthalpy Request (AUTO)
1 1 Override Local Economizer Enthalpy Request (ENABLED) bitfield
Binary
Outputs
5/15
Analog
Outputs
6/16
Unit
