Trane PIC - Supported Equipment; Parts List

Product description
BAS-SVX08D-E46
Supported equipment
Outdoor Chillers
Helical rotary compressor RTAA / RTAB / RTAC / RTAD / RTXA
Scroll compressor CGAN / CXAN / CGAH / CXAH / RAUL /
CGAM / CXAM
Centrifugal compressor CVAE
Indoor Chillers
Helical rotary compressor RTWB / RTUB / RTRA / RTHC / RTHD /
RTWD / RTUD
Scroll compressor CGWH / CGWN / CGCL / CCUH / CCUN
Centrifugal compressor CVGE / CVGF
Absorption ABSC / ABSD / ABTF
Rooftops
Reversible WSD / WSH / WKD / WKH
Cooling-only TCD / TCH / TED / TEH / TSD / TSH / TKD / TKH
Gas-fired YCD / YCH / YSD / YSH /YKD / YKH
Parts list
Table 1 - Parts list
Communication Boards Controller Type Equipment Drawing # Part Number
CH530 LCI-C Tracer CH530 RTAC Public Extension MOD 0160E
RTAC Chiller Profile MOD 0164E
RTHD MOD 0161E
SCROLL MOD 0162E
Centrifugal MOD 0163E
RTWD, RTUD MOD 0186E
RTAC, RTHD, CGAN..
(hardware only)
X13650845-002 MOD 01216
CH532 LCI-C V1.2 Tracer CH532 V1.2 CGAN/CXAN X 13740189-001 BRD0079E
CH532 LCI-C V2.0
Tracer CH532 V2.0, V2.3
and greater
CGAN/CXAN X 13740189-002 BRD0084E
UCM CLD LCI-C UCM CLD RTAA, RTAD, RTWB X 13651074-001 KIT 12182
UCM CLD CSR UCM CLD RTAA, RTAD, RTWB X 13650364-004 MOD01422
TCI4-Comm3 UCP2 RTHC X13650618-002 MOD00720
TCI4-Comm3 UCP2 CVGE X13650460-011 MOD01396
TCI Comm3-Comm4 Reliatel Rooftop X01650524-001 BRD03029
TCI Comm3-Comm4 UCP II / III Rooftop X13650464-004 BRD00917
