Trane PIC - Data Point List for CGAN;CXAN (Tracer CH532 V2.0)

Operation
29BAS-SVX08D-E4
Table 11 - Data Point List for CGAN/CXAN chillers,Tracer CH532 controller Version 2.0 and greater
Data Type Function Modbus Index Offset Point Description Unit
Binary
Outputs
5/15
00001 0 Chiller Enable/Disable Command (0=Disable) bit
00002 1 Chiller Mode (0=Cool) bit
00003 2 Circuit 1 Enable/Disable bit
00004 3 Circuit 2 Enable/Disable bit
Analog
Outputs
6/16
40001 0 Copy of function 5/15 binary points bitfield
40002 1 Chilled Water Setpoint Temperature
40003 2 Heating Setpoint Temperature
Binary Inputs 2
10002 1 Chiller Running Status bit
10003 2 Circuit 1 Fan 1 output bit
10004 3 Circuit 1 Fan 2 output bit
10005 4 Circuit 1 Fan 3 output bit
10006 5 Circuit 2 Fan 1 output bit
10007 6 Circuit 2 Fan 2 output bit
10008 7 Circuit 2 Fan 3 output bit
10009 8 Compressor A1 output bit
10010 9 Compressor B1C1 output bit
10011 10 Compressor A2 output bit
10012 11 Compressor B2C2 output bit
Analog Inputs 4
30001 0 Copy of function 2 binary points bitfield
30002 1 Active Chilled/Hot Water Setpoint Temperature
30003 2 Evaporator Leaving Water Temperature Temperature
30004 3 Evaporator Entering Water Temperature Temperature
30005 4 Condenser Entering Water Temperature Temperature
30006 5 Chiller Status (See Appendix) bitfield
30007 6 Circuit 1 saturated suction temperature Temperature
30008 7 Circuit 2 saturated suction temperature Temperature
30009 8 Circuit 1 saturated discharge temperature Temperature
30010 9 Circuit 2 saturated discharge temperature Temperature
30011-30012 10-11 Compressor A1 running hours Hours
30013-30014 12-13 Compressor B1C1 running hours Hours
30015-30016 14-15 Compressor A2 output running hours Hours
30017-30018 16-17 Compressor B2C2 running hours Hours
30019-30020 18-19 Compressor A1 starts None
30021-30022 20-21 Compressor B1C1 starts None
30023-30024 22-23 Compressor A2 starts None
30025-30026 24-25 Compressor B2C2 starts None
