Operation
BAS-SVX08D-E442
Table 15 - Continued
Unit
Data
Type
Offset Point DescriptionFunction
Modbus
Index
HVAC Unit Type ID
0 = CVHE/G
1 = CVHF
2 = CVHB
3 = CVGE
30054 53 4 = CVAE
5 = RTHA
6 = RTHB
7 = two stage absorption
8 = one stage absorption
9 = direct fired absorption None
30055 54 Chiller Module Software Revision Level None
30056 55 Circuit Module Software Revision Level None
30057 56 Stepper Module 1 Software Revision Level None
30058 57 ABS: Stepper Module 2 Software Revision Level None
30059 58 Starter Module Software Revision Level None
30060 59 CTV: Purge Module Software Revision Level None
30061 60 Options Module Software Revision Level None
30062 61 Comm Module (TCI IV) Software Revision Level None
30063 62 Local Human Interface Software Revision Level None
30064 63 Remote Human Interface Software Revision Level None
30065 64 Front Panel Chilled Water Setpoint Temperature
30066 65 CTV/RTH: Front Panel Current Limit Setpoint Percentage
30067 66 CTV: Front Panel Hot Water Setpoint Temperature
30068 67 CTV/RTH: Front Panel Ice Termination Setpoint Temperature
30069 68 Design Delta Temperature Temperature
30070 69 Differential To Start Setpoint Temperature
30071 70 Differential To Stop Setpoint Temperature
30072 71 CTV/RTH: Condenser Pressure Limit Setpoint Pressure
30073 72 Chiller Power UP/Start Delay Setpoint Temperature
30074 73 Rated Load Amps Percentage
30075 74 Low Rfgt Temp Cutout Temperature
30076 75 Leaving Water Temp Cutout Temperature
30077 76 Setpoint Source Overide None
30078 77 CTV: Control Type: 0 = Chilled Water ;
1 = Hot Water ; 2 = Control Externally None
Analog
Inputs
4
