Operation
41BAS-SVX08D-E4
Data
Type
Offset Point DescriptionFunction
Modbus
Index
30042 41 CTV: Outboard Bearing Temp
ABS: Strong Soln Temp Lvg LTHX Temperature
30043 42 CTV/RTH: Discharge Temp
ABS: Intermd Soln Temp at Absorber Spray Temperature
30044 43 ABS: LiBr Concentration Percentage
30045 44 ABS: LiBr Cryst Temp Temperature
30046 45 ABS: Absorber Entering Water Temp Temperature
30047 46 CTV: IGV Stepper Motor Position
ABS: Energy Valve Stepper Motor Position
RTH: EXV Stepper Motor Position" Percentage
30048 47 ABS: Dilute Solution Temp Lvg HTHX Temperature
30049 48 ABS: Dilute Solution Temp Ent HTG Temperature
Bit 0 RESERVED
Bit 1 CTV/RTH: Ice Machine Control
Bit 2 UNUSED
30050 49 Bit 3 UNUSED
Bit 4 UNUSED
Bit 5 UNUSED
Bit 6 ABS: Purge Status
Bit 7 ABS: PCL Switch Status bitfield
Bit 0 UNUSED
Bit 1 UNUSED
Bit 2 Chiller mode
30051 50 Bit 3 CTV/RTH/ABS: Base loading status
Bit 4 CTV: Free cooling status
Bit 5 CTV: Heat pump status
Bit 6 CTV: UNUSED
Bit 7 CTV: Hot gas bypass status bitfield
Bit 0 CTV: purge pumpout running
Bit 1 CTV: purge mode 1 = auto 0 = stop
Bit 2 Head relief request
30052 51 Bit 3 CTV: Oil pump relay
Bit 4 CTV: retired for Tracer (Cond. fan 4)
Bit 5 CTV: Condensor fan 3
Bit 6 CTV: Condensor fan 2
Bit 7 CTV: Condensor fan 1 bitfield
Bit 0 CTV: purge service pumout
Bit 1 CTV: purge liquid level
Bit 2 CTV: external heat pump
30053 52 Bit 3 CTV/RTH: external ice making
Bit 4 CTV: external free cooling
Bit 5 emergency stop
Bit 6 external auto/stop
Bit 7 CTV: purge compr running bitfield
Analog
Inputs
4
Table 15 - Continued
