Table 15 - Continued
Unit
Data
Type
Offset Point DescriptionFunction
Modbus
Index
Bit 0 RESERVED
Bit 1 RESERVED
Bit 2 Tracer
30017 16 Bit 3 External Direct Capacity Control
Bit 4 future 2
Bit 5 future 1
Bit 6 RESERVED
Bit 7 Front Panel bitfield
30018 17 CTV/RTH: Active Current Limit Setpoint Percentage
Bit 1 Ice Building
Bit 2 Tracer
Bit 3 RESERVED
30019 18 Bit 4 future 2
Bit 5 future 1
Bit 6 External Input
Bit 7 Front Panel bitfield
30020 19 CTV: Active Hot Water Setpoint Temperature
Bit 0 RESERVED
Bit 1 RESERVED
Bit 2 Tracer
30021 20 Bit 3 External Direct Capacity Control
Bit 4 future 2
Bit 5 future 1
Bit 6 External Input
Bit 7 Front Panel bitfield
30022-30023 21-22 CTV/RTH: Compressor Running Seconds Seconds
30024 23 CTV/RTH: Compressor Starts None
30025 24 RTH: Compressor Discharge Refrigerant Temperature
30026 25 Saturated Evap Refrigerant Temp Temperature
30027 26 Saturated Cond Refrigerant Temp Temperature
30028 27 CTV\RTH: Saturated Evap Refrigerant Press Pressure
30029 28 CTV\RTH: Saturated Cond Refrigerant Press Pressure
30030 29 CTV\RTH: Compressor Winding 1 Temp Temperature
30031 30 CTV\RTH: Compressor Winding 2 Temp Temperature
30032 31 CTV\RTH: Compressor Winding 3 Temp Temperature
30033 32 CTV: Oil Sump Temp Temperature
30034 33 CTV: Condenser Rfgt Pressure Pressure
30035 34 CTV/RTH: Rfgt Type 5 = WATER 4 = R22
3 = R134A 2 = R12 1 = R11 0 = R123 None
30036 35 Restart Inhibit Timer None
30037 36 CTV\RTH: Cmpr Phase A Current Draw
ABS: Soln Pump Phase A Current Draw Percentage
30038 37 CTV\RTH: Cmpr Phase B Current Draw
ABS: Soln Pump Phase B Current Draw Percentage
30039 38 CTV\RTH: Cmpr Phase C Current Draw
ABS: Soln Pump Phase C Current Draw Percentage
30040 39 CTV/ABS: Power None
30041 40 CTV: Inboard Bearing Temp
ABS: Dilute Soln Temp Lvg Absorber Temperature
Analog
Inputs
