Operation
BAS-SVX08D-E444
Table 16 - Continued
Unit
Data
Type
Offset Point DescriptionFunction
Modbus
Index
Bit 0 Compressor Lockout (Lockout Both) (1 = Not Locked Out 0 = Lock Out)
Bit 1 Auxiliary Heat Lockout (1 = Not Locked Out 0 = Lock Out)
Bit 2 Lead/Lag Enable/Disable (1 = Enabled 0 = Disabled)
40009 8 Bit 3 Zone Temperature Source (1 = Echelon 0 = Local)
Bit 4 Economizer Min Position Setpoint Source (1 = ICS 0 = Local)
Bit 5 Power Exhaust Setpoint Source (1 = ICS 0 = Local)
Bit 6 Reset Select Input Source (VAV Only) (1 = ICS 0 = Local)
Bit 7 Tracer Has Not Written (1 = Yes 0 = No) bitfield
40010 9 Reserved for BAS 1 None
40011 10 Reserved for BAS 2 None
10004 3 Gemini Unit (1 = Yes 0 = No) bit
10005 4 Economizer Installed (1 = Installed 0 = Not Installed) bit
10006 5 Gas or Electric (1 = Gas Heat 0 = Electric Heat) bit
10007 6 Heat Pump (Voyager I & II Only) (1 = Yes 0 = No) bit
10008 7 Compressor 1 Exists (1 = Yes 0 = No) bit
10009 8 Compressor 1 Cycling Input (1 = Normal 0 = Disabled) bit
10010 9 HPC for Compressor 1 (1 = High Press 0 = Normal) bit
10011 10 Compressor 1 Locked Out (1 = Yes 0 = No) bit
10012 11 Compressor On or Off (1 = On 0 = Off) bit
10013 12 Compressor 2 Exists (1 = Yes 0 = No) bit
10014 13 Compressor 2 Cycling Input (1 = Normal 0 = Disabled) bit
10015 14 HPC for Compressor 2 (1 = High Press 0 = Normal) bit
10016 15 Compressor 2 Locked Out (1 = Yes 0 = No) bit
10017 16 Compressor On or Off (1 = On 0 = Off) bit
10019 18 Return Humidity Sensor Failed (1 = Yes 0 = No) bit
10020 19 Return Air Temperature Sensor Failed (1 = Yes 0 = No) bit
10021 20 Outdoor Humidity Sensor Failed (1 = Yes 0 = No) bit
10022 21 Supply Air Temperature Sensor Failed (Mixed) (1 = Yes 0 = No) bit
10023 22 Outdoor Air Temperature Sensor Failed (1 = Yes 0 = No) bit
10024 23 Zone Temperature Sensor Failed (1 = Yes 0 = No) bit
10025 24 Economizer Fault (1 = Yes 0 = No) bit
10026 25 Coil Temperature Sensor Failed (1 = Yes 0 = No) bit
10027 26 Local Zone Cooling Setpoint Failed (1 = Yes 0 = No) bit
10028 27 Local Zone Heating Setpoint Failed (1 = Yes 0 = No) bit
10030 29 Filter Clogged Failure (1 = Yes 0 = No) bit
10031 30 Heat Failure (1 = Yes 0 = No) bit
10032 31 High Temperature Input is Hot / Smoke Detector (1 = Yes 0 = No) bit
10033 32 Heat Stage 3 Exists (1 = Yes 0 = No) bit
10034 33 Heat Stage 2 Exists (1 = Yes 0 = No) bit
10035 34 Not Used - Reserved for UCP (1 = Yes 0 = No) bit
10036 35 Emergency Heat Mode (Heat Pump Only) (1 = Yes 0 = No) bit
10037 36 Supply Fan Mode (1 = On 0 = Auto) bit
10038 37 Manual/Auto Mode (1 = Manual 0 = Auto) bit
10039 38 Heat/Cool Mode (1 = Cool 0 = Heat) bit
10040 39 Off Mode (1 = Off 0 = Auto) bit
10041 40 Timed Override Request (1 = Yes 0 = No) bit
10042 41 Test Mode in Progress (1 = Yes 0 = No) bit
10043 42 Decision to Economize (1 = Enabled 0 = Disabled) bit
10045 44 Power Up Failure has Occurred (1 = Yes 0 = No) bit
10046 45 Heat Pump Defrost is Active (1 = Yes 0 = No) bit
10047 46 Evaporator Defrost is Active (1 = Yes 0 = No) bit
Binary
Inputs
2
Analog
Outputs
6/16
