Operation
45BAS-SVX08D-E4
Data
Type
Offset Point DescriptionFunction
Modbus
Index
10048 47 Supply Air Tempering is Active (1 = Yes 0 = No) bit
10049 48 Exhaust Fan is Energized (1 = Yes 0 = No) bit
10050 49 Condenser Fan A is Energized (1 = Yes 0 = No) bit
10051 50 Condenser Fan B is Energized (1 = Yes 0 = No) bit
10052 51 Heat Output 1 is Energized (1 = Yes 0 = No) bit
10053 52 Heat Output 2 is Energized (1 = Yes 0 = No) bit
10054 53 Reverse Valve is Energized (1 = Yes 0 = No) bit
10055 54 Supply Fan is Energized (1 = Yes 0 = No) bit
10059 58 Clogged Filter Local Input (1 = Yes 0 = No) bit
10060 59 Compressor 2 Cycling Input (1 = OK 0 = Bad) bit
10061 60 Compressor 1 Cycling Input (1 = OK 0 = Bad) bit
10065 64 Default Defrost Flag bit
10066 65 Demand Defrost Fault C Flag bit
10067 66 Demand Defrost Fault B Flag bit
10068 67 Demand Defrost Fault A Flag bit
10069 68 Fan Failure (1 = Failed 0 = Ok) bit
10070 69 Heat Failure (1 = Open 0 = Closed) bit
10071 70 HPC for Compressor 2 (1 = High Press 0 = Normal) bit
10072 71 HPC for Compressor 1 (1 = High Press 0 = Normal) bit
30001 0 Outdoor Air Temperature Sensor Value Temperature
30002 1 Zone Temperature Sensor Value Temperature
30003 2 Mixed Air Temperature Sensor Value Temperature
30004 3 Return Air Temperature Sensor Value Temperature
30005 4 Local Zone Cooling Setpoint Input Temperature
30006 5 Local Zone Heating Setpoint Input Temperature
30007 6 Actual Zone Cooling Setpoint Temperature
30008 7 Actual Zone Heating Setpoint Temperature
30009 8 Outdoor Air Relative Humidity Sensor Value ( 10.0 to 90.0 %) Percentage
30010 9 Return Air Relative Humidity Sensor Value ( 10.0 to 90.0 %) Percentage
30011 10 Local Economizer minimum position Range ( 0.0 to 50.0 %) Percentage
30012 11 Actual Economizer Damper Position Range ( 0.0 to 100.0 %) Percentage
30013 12 Number of Cooling Stages Active ( 0 to 3) None
30014 13 Number of Heating Stages Active ( 0 to 3) None
30016 15 Reference Enthalpy Switch Settings ( 22, 23, 25 or 27 BTU/LBM) None
Bit 0 Gas or Electric (1 = Gas Heat 0 = Electric Heat)
Bit 1 Heat Pump (Voyager I & II Only) (1 = Yes 0 = No)
Bit 2 Voyager III Unit (1 = Yes 0 = No)
30018 17 Bit 3 Economizer Installed (1 = Installed 0 = Not Installed)
Bit 4 Gemini Unit (1 = Yes 0 = No)
Bit 5 Not Used - Reserved for UCP
Bit 6 Not Used - Reserved for UCP
Bit 7 Not Used - Reserved for UCP bitfield
Bit 0 Compressor On or Off (1 = On 0 = Off)
Bit 1 Compressor 1 Locked Out (1 = Yes 0 = No)
Bit 2 HPC for Compressor 1 (1 = High Press 0 = Normal)
30019 18 Bit 3 Compressor 1 Cycling Input (1 = Normal 0 = Disabled)
Bit 4 Compressor 1 Exists (1 = Yes 0 = No)
Bit 5 Compressor 1 is Lead (1 = Yes 0 = No)
Bit 6 Not Used - Reserved for UCP
Bit 7 Not Used - Reserved for UCP bitfield
Analog
Inputs
4
Binary
Inputs
2
Table 16 - Continued
Unit
